EY507 176.7 195.5 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY508 188 166.5 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY509 135.5 202.7 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY510 110.5 117.3 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY511 197.5 204.5 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY512 175.5 204.5 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY601 217.5 31.5 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY602 192.5 56.5 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY603 192.5 36.5 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY604 217.5 46.5 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY605 225 67.6 6042-000001 EYELET EYELET 2.2 HOLE 3.0 PAD 5.0
EY606 132.6 70.6 6042-000001 EYELET EYELET 2.2 HOLE 3.0 PAD 5.0
EY607 143 127.5 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY608 243.2 67.6 6042-000001 EYELET EYELET 2.2 HOLE 3.0 PAD 5.0
EY609 114.4 70.6 6042-000001 EYELET EYELET 2.2 HOLE 3.0 PAD 5.0
EY610 225 20.4 6042-000001 EYELET EYELET 2.2 HOLE 3.0 PAD 5.0
EY611 278.5 27 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY612 243.2 20.4 6042-000001 EYELET EYELET 2.2 HOLE 3.0 PAD 5.0
EY613 292.3 55.8 6042-000002 EYELET EYELET 1.5 HOLE 2.2 PAD 4.0
EY614 245.8 91.8 6042-000001 EYELET EYELET 2.2 HOLE 3.0 PAD 5.0
EY615 245.8 81.8 6042-000001 EYELET EYELET 2.2 HOLE 3.0 PAD 5.0
FG601 295 10 3601-000004 FUSE-FERRULE 250V,3.15A,SLOW BLOW,CERAMIC,5
FH601 305.3 9.8 3602-000001 FUSE-CLIP,5.2X20,30MOHM 800GF,400-800GF
HS102 BH62-30410A HEAT/SINK A6063S,T2.5
HS301 BH62-30411A HEAT/SINK A6063S,T2.0
HS501 BH62-30417A HEAT/SINK-FBT A1050S,T1.0,CKA42*7/5227
HS508 BH62-30015A HEAT/SINK-TR SCP-1,T1,SN
HS602 BH62-30411A HEAT/SINK A6063S,T2.0
IC101 274.5 141 1201-001184 IC-VIDEO AMP 2141,DIP,20P,300MIL,SINGLE,P
IC102 281.5 241 1204-000010 IC-CHANNEL SELECTOR LM2406,T0-220,11P,PLASTIC,85
IC201 38 32 1203-001274 IC-VOL. DETECTOR 7545,TO-92,3P,PLASTIC,4.35/4
IC202 34 48.5 BH09-10303T IC-MICOM MASKING CKA,LSC442839B,SYNC-PROCESSOR
IC203 80 19.5 1103-001020 IC-EEPROM 24LC04,4Kx8BIT,DIP,8P,300MIL
IC204 63.5 122 1103-001009 IC-EEPROM 24LC21,128X8BIT,DIP,8P,300MIL
IC301 112 50.8 1204-000013 IC-VERTICAL PROCESSO TDA9302H,TO-220,9P,PLASTIC,3
IC302 92.5 25.5 1201-001034 IC-AMPLIFIER L272M,DIP,8P,28V,1A,1W,STICK
IC401 40 146.8 1204-001231 IC-DEF. PROCESSOR TDA9109,DIP,32P,300MIL,PLASTIC
IC601 183 9.5 1203-000002 IC-LIN,431,REGULATOR TO-92,3,36V(T)-SIMPLE
IC602 246 38 BH13-10334H IC G-PROJECT, KA2H0880, SIP, 5P, FET
IC603 73.8 8 1203-000001 IC-POSI.ADJUST REG. 7805,TO-220,3P,PLASTIC,4.8/5
IC604 31 177.5 1203-000165 IC-LIN,KA78R12,REGULATOR TO-220,4,5V
IS601 303.3 29 3721-001006 PLUG-AC POWER 3P,10/24mm,SN
J14 BH39-40305U JUMPER-WIRE JUMPER-WIRE 14”
J15 BH39-40305U JUMPER-WIRE JUMPER-WIRE 15” SDD
JP209 BH39-40305U JUMPER-WIRE JUMPER-WIRE 14”
L101B 287 200.8 2701-001036 INDUCTOR-AXIAL 1.2uH,10%,9.8x4.2mm
L101G 274.3 206.5 2701-001036 INDUCTOR-AXIAL 1.2uH,10%,9.8x4.2mm
!
!
!
!
10 PCB Diagrams and Electrical Parts List
CKA42*7L/5227L 10-9
Loc. No. Coordinates (X,Y) New Code No. Description Specification Remarks
