Samsung SYNCM.400B - Page 8

C414 108 236 2303-000305 C-FILM,PPF 3nF,5%,1.6KV,29x13.5x8mm,25mm
C415 114.5 236 2303-000305 C-FILM,PPF 3nF,5%,1.6KV,29x13.5x8mm,25mm
C416 62 230.5 2305-000179 C-FILM,MPEF 10nF,5%,250V,14.5x8.8mm,10mm,B
C417 132.8 229 2301-000133 C-FILM,PEF 10nF,10%,100V,6.5x12.5mm,5mm,T
C420 48 180.5 2401-000023 CAP-AL.ELEC,105M,1H (T)50V 1M
C421 75 137.5 2201-000643 C-CERAMIC,DISC 680pF,10%,50V,Y5P,4x3.5,5,TP
C422 43 218 2306-000171 C-FILM, MPPF 270nF,5%,250V,21.5x12.5mm,7.5mm 14”
2306-000137 C-FILM, MPPF 180nF,5%,250V,19x16.5x8mm,7.5mm 15” SDD
2306-000171 C-FILM, MPPF 270nF,5%,250V,21.5x12.5mm,7.5mm 15” Philips
C423 53.5 211 2306-000007 C-FILM,MPPF 470nF,5%,250V,26.5x14mm,22.5mm 15” Philips
2306-000249 C-FILM,MPPF 680nF,5%,250V,26x20.5x12mm,20mm 14”
2306-000197 C-FILM,MPPF 390nF,5%,250V,20x19x12mm,17.5mm 15” SDD
C424 33.5 211 2306-000234 C-FILM,MPPF 560nF,5%,250V,26.5x15mm,22.5mm 15” Philips
2306-000249 C-FILM,MPPF 680nF,5%,250V,26x20.5x12mm,20mm 14”
2301-001159 C-FILM,MPPF 540nF,5%,250V 15” SDD
C425 33 161.5 2401-000042 C-AL 100uF,20%,16V,GP,6.3x7mm,2.5mm
C426 36.5 163 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,2.3X3.0
C427 60 167.5 2301-000168 C-FILM,PEF 150nF,5%,100V,11.5x19mm,7.5mm
C428 26 222.5 2401-000023 CAP-AL.ELEC,105M,1H (T)50V 1M
C429 15.5 222.5 2401-000023 CAP-AL.ELEC,105M,1H (T)50V 1M
C430 61.5 161.5 2305-000001 C-FILM,MPEF 470nF,10%,63V,6.0X15.5X7.5,5mm
C431 33 168.8 2401-000042 C-AL 100uF,20%,16V,GP,6.3x7mm,2.5mm
C432 39.5 163 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,2.3X3.0
C433 69.5 169 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,2.3X3.0
C434 73.5 168.8 2401-001509 C-AL 47uF,20%,16V,GP,6.3x7mm,2.5mm
C435 152.5 117 2401-001012 C-ALUMINUM 3.3UF,20%,50V,BP,16+26.7,7.5mm,T
C436 129 188 2303-001029 C-FILM,PPF 5.2nF,5%,630V,19x7x13,7.5,TP
C437 155.5 147 2301-000012 CAP-MYLAR,222J,2A,5P (T)100V 222J
C439 154 137.8 2201-000010 CAP-CERAMIC,330J,1H,NPO 33PF,50V,5%,NPOPPM,NPO,DISC
C440 80.5 134.5 2301-000016 C-FILM,PEF 22nF,5%,100V,7.2x4.5x9.0mm,5mm
C441 185 135.5 2301-000012 CAP-MYLAR,222J,2A,5P (T)100V 222J
C442 84 116 2201-000326 C-CERAMIC,DISC 2.2nF,10%,50V,Y5P,6.3X3.0,5,TP
C443 36 141.5 2301-000016 C-FILM,PEF 22nF,5%,100V,7.2x4.5x9.0mm,5mm
C445 50.8 171.8 2401-000050 C-AL 10uF,20%,16V,GP,5x11mm,2mm,TP
C501 92.5 168.5 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,2.3X3.0
C502 98.8 150 2401-000966 C-AL 22uF,20%,50V,GP,6.3x11mm,5mm,T
C503 170.5 119.5 2305-000004 C-FILM,MPEF 220nF,10%,100V,12.7x16,5mm,TP
C504 85.5 174.5 2202-002009 C-CERAMIC,MLC-AXIAL 100nF,+80-20%,50V,Y5V,2.3X3.0
C505 170.5 126 2305-000004 C-FILM,MPEF 220nF,10%,100V,12.7x16,5mm,TP
C507 219 205.3 2201-000017 C-CERAMIC,DISC 1nF,10%,50V,Y5P,4x3.5,5,TP
C508 207.5 144.5 2401-000046 CAP-AL.ELEC,106M,2E (T)250V 10M
C509 203.5 241 2401-001334 C-AL 470nF,20%,50V,GP,5x11mm,2mm,TP
C511 117.5 149 2201-000469 C-CERAMIC,DISC 330pF,10%,500V,Y5P,6x3.5,5,TP
C512 130 137.5 2306-000007 C-FILM,MPPF 470nF,5%,250V,26.5x14mm,22.5mm
C515 186.8 125.8 2201-000017 C-CERAMIC,DISC 1nF,10%,50V,Y5P,4x3.5,5,TP
C516 186.8 129.5 2201-000471 C-CERAMIC,DISC 330pF,10%,50V,Y5P,4x3.5,5,TP
C517 140 91 2401-000033 C-AL 100uF,20%,100V,GP,13x20mm,5mm
!
!
10 PCB Diagrams and Electrical Parts List
CKA42*7L/5227L 10-5
Loc. No. Coordinates (X,Y) New Code No. Description Specification Remarks
