Samsung SyncMaster 15GLe - Appendix Specifications; Input Signal

15
his section of the User’s Manual
contains important reference infor-
mation such as the monitor’s
Specifications ( page 15 ), important FCC
and IC operating information ( page 16
and 17 ), Pin assignments ( page 17 ), and
the Factory Modes Timing Signal Chart.
( pages 18 and 19 ).
Specifications
Picture Tube
l 38 cm ( 15” ) Flat Face Tube Type [35 cm ( 13.8” ) visual.
l 90° Deflection
l 0.28 dot pitch, Semi-tint, Non-glare
l Anti-Static Silica coating
l lnvar Shadow Mask
Synchronization l Horizontal: 30 kHz to 50 kHz ( automatic )
l Vertical: 50 Hz to 120 Hz ( automatic )
Display Color
Maximum Resolution
Active Display Size
Maximum Display Size
Input Signal
Maximum Pixel Clock
Power Supply
Power Consumption
Dimensions/Weight
(Approximately)
Environmental Considerations
l Unlimited colors
l Horizontal: 1024 dots
l Vertical: 768 lines
l Horizontal: 267 mm ± 3 mm ( 10.5” + 0.19” )
l Vertical: 200 mm ± 3 mm ( 7.87” ± 0.19” )
( Active display size is changed by timing signal )
l Horizontal: 280 mm ( 11.02” )
l Vertical: 210 mm ( 8.27” )
l Video Signal: Analog 0.714 Vpp
Positive at 75 Terminated
l Separate Sync.: TTL Level, Positive or Negative
l Composite Sync.: TTL Level, Positive or Negative
l 65MHz
l AC100-240Volt±10%,60Hz/50Hz±3Hz
l 85 Watt maximum
l Unit: 393.5 x 373 x 400 mm; 13.3 kg
15.5” x 14.7” x 15.7” ( H x W x D ) 29.3 lb
l Carton: 450 x 465 x 517 mm; 15.3 kg
17.7” x 18.3” x 20.4” ( H x W x D ) 33.7 lb
l Operating Temperature: 32°F to 104°F
( 0°C to 40°C ) Humidity: 10% to 80%
l Storage Temperature: -4°F to 113°F
( -20°C to 45°C )- Humidity: 5% to 95%
Note: Design and specifications are subject to change without prior notice.
