Samsung SyncMaster 15GLe - Factory Modes Timing Signal Chart

18
Factory Modes Timing
Signal Chart
Mode
IBM
VESA
VGA1/70Hz
VGA2/70Hz
VGA3/60Hz XGA/87iHz
800/60Hz
Timing
640X350
720X400 640X480
1024X768
800x600
fH (kHz)
31.469
31.469
31.469
35.522
37.879
A
µsec 31.778
31.777
31.778 28.151
26.400
B
µsec 3.813
3.813
3.813 3.920
3.200
C
µsec
1.907
1.907
1.907 1.247
2.200
D
µsec
25.422
25.422
25.422 22.806
20.000
E
µsec
0.636
0.636
0.636 0.178
1.000
fv
(Hz)
70.086
70.087
59.940
86.958
60.317
O msec
14.268
14.268
16.683 11.500
16.579
P msec
Q msec
R msec
S msec
Clock Freq.
(MHz)
Polarity
H.-Sync.
V.-Sync.
Remark
0.064
0.064
0.064
1.907
1.080
1.048
11.122
12.711
15.253
1.176
0.413
0.318
25.175
28.322
25.175
Positive Negative Negative
Negative
Positive Negative
0.113
0.106
0.563
0.607
10.810
15.840
0.014
0.026
44.900
40.000
Positive Positive
Positive
Positive
Interlace
Horizontal
Vertical
ENGLISH
n
