5. Exploded View and Parts List
5-3. LS22PEBSFV/EDC Parts List
Level Location Code.No Item & Specication Q’ty SA/SNA Remark
LS22PEBSFV/EDC 2232BW,WSK1/S22P0-LPE,22,LCD-MO,NETHERLA
0.1 M0001 BN90-01323A ASSY COVER FRONT;LS22PE,2232BW 1 S.N.A
..2 T0003 BN96-05536A ASSY COVER P-FRONT;LS22PEW,ABS HB,BK26,H 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
...3 BN61-03222A GUIDE-PANEL;LS17PEW,SECC,T 0.5 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.5 S.N.A
...3 M0112 BN63-03529A COVER-FRONT;LS22PEW,ABS,HB,BK26,H/GLOSSY 1 S.N.A
...3 T0022 BN64-00534B KNOB CONTROL;PEBBLE,ABS,HB,BK26 1 S.N.A
...3 T0023 BN64-00597B KNOB POWER;PEBBLE,black highglossy 1 S.N.A
...3 M0130 BN67-00193A LENS LED;PEBBLE,ABS HB,CLR 1 S.N.A
...3 M0145 BN96-04363B ASSY BOARD P-FUNCTION;Pebble_2032_2232,S 1 S.A
0.1 M0002 BN90-01324A ASSY COVER REAR;LS22PE 1 S.N.A
..2 M0013 BN96-05535A ASSY COVER P-REAR;LS22PEW,ABS HB,BK26,H/ 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 T0060 BN61-02830A SPRING ETC;PEBBLE,SK5,1.0,LS19PEB,HRC 45 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.5 S.N.A
...3 M0014 BN63-02880B COVER-STAND BAR;PEBBLE,ABS HB,T2.6,BK26, 1 S.N.A
...3 BN63-02883B COVER-HINGE;PEBBLE,ABS HB,T2.6,BK26,HF-0 1 S.N.A
...3 M0006 BN63-03533A COVER-REAR;LS22PEW,ABS,HB,BK26,H/GLOSSY 1 S.N.A
...3 T0102 BN73-00132B RUBBER-CAP;PEBBLE,ELASTOMER,BK07,HB 1 S.N.A
0.1 M0107 BN91-01517P ASSY LCD-CTZ;LS22PEB* 1 S.N.A
..2 M0215 BN07-00427A LCD-PANEL;M220Z1-L03,Mendel,6bit Hi-FRC, 1 S.A
0.1 M0017 BN91-01630R ASSY CHASSIS-CTZ,W/W;LS22PEBSF/XAA 1 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 3 S.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 4 S.N.A
..2 M0174 BN44-00127Q IP BOARD;IP-45130B,PEBBLE 22”,3.0 ~5.0mA 1 S.A
..2 M0014 BN94-01340Z ASSY PCB MAIN-CTZ,W/W;LS22PEBSF 1 S.N.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.003 S.N.A
...3 CN102 3701-001173 CONNECTOR-DVI;24P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 CN101 3701-001219 CONNECTOR-DSUB;15P,3R,FEMALE,ANGLE,AUF 1 S.A
...3 HDCP BN97-00707A ASSY HDCP;BN46-00018A,BR20/21BS_CS,MSTAR 1 S.N.A
....4 BN46-00018A KEY CODE-CERTIFICATE;(HDCP KEY)PPM42M5S, 1 S.N.A
...3 T0174 BN97-01626Z ASSY SMD;LS22PEB 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45㎛,96.5Sn/ 0.799 S.N.A
....4 D100 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D101 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D102 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D103 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D104 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D105 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D106 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D107 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D108 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
