5. Exploded View and Parts List
Level Location Code.No Item & Specication Q’ty SA/SNA Remark
....4 C632 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C633 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C634 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C638 2203-005437 C-CER,CHIP;10000nF,+80-20%,10V,Y5V,3216 1 S.A
....4 C722 2402-001081 C-AL,SMD;100uF,20%,25V,WT,TP,8.3x8.3x10 1 S.A
....4 C435 2402-001128 C-AL,SMD;100μF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C629 2402-001128 C-AL,SMD;100μF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C639 2402-001128 C-AL,SMD;100μF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C719 2402-001128 C-AL,SMD;100μF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 C725 2402-001128 C-AL,SMD;100μF,20%,16V,-,TP,6.3X5.7mm 1 S.A
....4 X1 2801-003667 CRYSTAL-SMD;14.31818MHz,30ppm,28-AAN,16p 1 S.A
....4 T0568 3301-001407 BEAD-SMD;30ohm,1608,300mA,TP,,,0.4ohm 1 S.N.A
....4 T0568 3301-001407 BEAD-SMD;30ohm,1608,300mA,TP,,,0.4ohm 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 T0568 3301-001569 BEAD-SMD;600ohm,2012,1000mA,TP,520ohm/90 1 S.N.A
....4 CN400 3708-001150 CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-A,SN,Y 1 S.A
....4 CN330 3711-005503 HEADER-BOARD TO CABLE;BOX,9P,1R,2mm,SMD- 1 S.A
....4 CN330 3711-005509 HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S 1 S.A
....4 L701 BN27-00008A COIL CHOKE-SMD;SMD12*12*8.5,GH15/17PS,22 1 S.A
....4 MICOM BN97-01647K ASSY MICOM-CTZ,W/W;LS22PEB* 1 S.N.A
.....5 IC109 1205-003255 IC-LCD CONTROLLER;SE758MRH-LF,PQFP,128P, 1 S.A
....4 T0077 BN41-00890A PCB MAIN;PEBBLE,CM-3,4,1.0,1.6T,179.6mm 1 S.N.A
....4 T0568 3301-001145 BEAD-SMD;60ohm,4516,TP,70ohm/45MHz,82ohm 1 S.N.A
....4 IC104 0801-002478 IC-CMOS LOGIC;7SZ14,SCHMITT TRIGGER,SOT2 1 S.A
....4 R256 2007-000075 R-CHIP;220ohm,5%,1/10W,TP,1608 1 S.A
....4 R257 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R258 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
..2 M0006 BN96-05533A ASSY SHIELD P-COVER;LS20PEW,SECC,T0.8 1 S.N.A
...3 BN61-02429D STUD-PEM;PNB,M2.8,D7,L20,ZPC(SIL),SUM24L 1 S.N.A
...3 M0107 BN63-03531A SHIELD-COVER;LS20PEW,SECC,T 0.8 1 S.N.A
...3 M0131 BN63-03831A GASKET;PEBBLE,71TS-FK 10-2-110-15,2T,10m 3 S.N.A
..2 M0596 BN96-05621A ASSY MISC P-FLAT CABLE;Mendel,FLAT CABLE 1 S.A
..2 M2893 AB39-00119A LEAD CONNECTOR;ORION,UL1007#26,UL/CSA,9 1 S.A
..2 T0514 BN61-02784A BRACKET-SUPPORT;PEBBLE,SPTE,0.3 1 S.N.A
0.1 M0112 BN91-01649A ASSY SHIELD;LS22PE 1 S.N.A
..2 BN63-03532A SHIELD-LAMP;LS20PEW,SPTE,T 0.3 1 S.N.A
0.1 M0113 BN92-02621L ASSY P/MATERIAL;LS22PEBSF/XAA 1 S.N.A
..2 T0376 6902-000001 BAG AIR;LDPE,T0.2,L1800,W1000,TRP,,,LDPE 0.001 S.N.A
..2 T0376 6902-000061 BAG AIR;LDPE,T0.2,L1000,W500,TRP,,, 0.009 S.N.A
..2 T0524 6902-000241 BAG PE;NITRON/HDPE,T0.5/T0.012,W600,L600 1 S.N.A
..2 T0003 6902-000604 BAG WRAPPING;LDPE,T0.02,W500,L10000,TRP, 1.09 S.N.A
