Samsung SyncMaster 320TFT - Electrical Parts List

BD101 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
BD102 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
BD103 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
BD104 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
BD105 2703-001334 INDUCTOR-SMD 1.5uH,10%,2x1.25x0.85mm
C100 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C101 2402-000168 C-AL,SMD 100uF,20%,16V,TP,8x6.3
C102 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C103 2402-000168 C-AL,SMD 100uF,20%,16V,TP,8x6.3
C104 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C105 2402-000168 C-AL,SMD 100uF,20%,16V,TP,8x6.3
C106 2402-000168 C-AL,SMD 100uF,20%,16V,TP,8x6.3
C107 2203-000239 C-CERAMIC,CHIP 100pF,5%,50V,NPO,TP,2012
C108 2203-000239 C-CERAMIC,CHIP 100pF,5%,50V,NPO,TP,2012
C109 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C110 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C111 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C112 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C113 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C114 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C115 2404-000123 C-TA,CHIP 10uF,20%,16V,TP,6032,2.9mm
C116 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C117 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C118 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C119 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C120 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C121 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C122 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C123 2203-000609 C-CERAMIC,CHIP 22nF,10%,50V,X7R,TP,2012
C124 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C125 2203-000609 C-CERAMIC,CHIP 22nF,10%,50V,X7R,TP,2012
C126 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C127 2203-000609 C-CERAMIC,CHIP 22nF,10%,50V,X7R,TP,2012
C128 2203-000137 C-CERAMIC,CHIP 1.5nF,10%,50V,NPO,TP,2012
C129 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C130 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C131 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C132 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C133 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C134 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C135 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C136 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C137 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C138 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C139 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
9 Electrical Parts List
SyncMaster 320TFT/520TFT 9-1
Loc. No. Code No. Description Specification Remarks
9 Electrical Parts List
9-1 Main PCB Parts
