Samsung SyncMaster 320TFT - Page 31

C392 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C393 2203-000455 C-CERAMIC,CHIP 1nF,5%,50V,NPO,TP,2012
C394 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C395 2203-000455 C-CERAMIC,CHIP 1nF,5%,50V,NPO,TP,2012
C396 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C397 2203-000455 C-CERAMIC,CHIP 1nF,5%,50V,NPO,TP,2012
C398 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C401 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C402 2404-000123 C-TA,CHIP 10uF,20%,16V,TP,6032,2.9mm
C403 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C404 2404-000123 C-TA,CHIP 10uF,20%,16V,TP,6032,2.9mm
C405 2203-000455 C-CERAMIC,CHIP 1nF,5%,50V,NPO,TP,2012
C406 2404-000123 C-TA,CHIP 10uF,20%,16V,TP,6032,2.9mm
C407 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C408 2402-000168 C-AL,SMD 100uF,20%,16V,TP,8x6.3
C409 2404-000123 C-TA,CHIP 10uF,20%,16V,TP,6032,2.9mm
C410 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C411 2203-000203 C-CERAMIC,CHIP 100nF,10%,16V,X7R,TP,2012
C412 2404-000123 C-TA,CHIP 10uF,20%,16V,TP,6032,2.9mm
C413 2203-000555 C-CERAMIC,CHIP 20pF,5%,50V,NPO,TP,2012
C414 2203-000555 C-CERAMIC,CHIP 20pF,5%,50V,NPO,TP,2012
C415 2404-000123 C-TA,CHIP 10uF,20%,16V,TP,6032,2.9mm
C416 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C417 2203-000239 C-CERAMIC,CHIP 100pF,5%,50V,NPO,TP,2012
C418 2203-000260 C-CERAMIC,CHIP 10nF,10%,50V,X7R,TP,2012
C419 2404-000123 C-TA,CHIP 10uF,20%,16V,TP,6032,2.9mm
CFT302 2901-001115 FILTER-EMI SMD 50VDC,500mADC,20pF,3.1x
CFT317 2901-001112 FILTER-EMI SMD 50VDC,1.0ADC,85pF+-20%
CFT318 2901-001115 FILTER-EMI SMD 50VDC,500mADC,20pF,3.1x
CFT319 2901-001112 FILTER-EMI SMD 50VDC,1.0ADC,85pF+-20%
CIS BN13-10001D IC-HYBRID/INVERTER LXB310T,SIC180,IN
CL101 BN27-20001C COIL-SMD 105UH,20%,SMD,TAPING
CL102 BN27-20001A COIL-CHOKE 53.0UH,20%,DR10*5,TRAY
CN101 3701-001117 CONNECTOR-DSUB 26P,2R,FEMALE,ANGLE,AU
CN102 3722-000117 JACK-DC POWER 3P,3.5mm,AG,BLK,NO
CN103 3711-000556 CONNECTOR-HEADER BOX,12P,1R,1.25mm,SMD-A
CN103_PANEL BN39-40001B CBF-HARNESS 12P/6P,100MM,BLU/WHT/BLK,UL1 13.3”
BN39-40001G CBF-HARNESS 12P,200MM,BLU/WHT/RED.UL1571 15”
CN301 3711-003161 CONNECTOR-HEADER BOX,20P,1R,1.25mm,ANGLE
CN301_PANEL BN39-40001K CBF-HARNESS 20P,200MM,BLK,UL2835,AWG28(2 13.3”
BN39-40001J CBF-HARNESS 20P,170MM,BLK,UL2835,AWG28-20C 15”
CN401 3711-001031 CONNECTOR-HEADER BOX,6P,1R,2.50mm,ANGLE
CN401_CN861 BN39-40001E CBF-HARNESS 6P,280MM,BLK,UL2464,AWG24-6C
D101 0401-000191 DIODE-SWITCHING MMBD4148,50V,DL-35,TP
D102 0401-000191 DIODE-SWITCHING MMBD4148,50V,DL-35,TP
D103 0401-000191 DIODE-SWITCHING MMBD4148,50V,DL-35,TP
D104 0401-000191 DIODE-SWITCHING MMBD4148,50V,DL-35,TP
9 Electrical Parts List
SyncMaster 320TFT/520TFT 9-5
Loc. No. Code No. Description Specification Remarks
