Samsung SyncMaster 570S TFT

24
Specifications
Table 7. Technical and environmental specifications
Panel Size
Display Size
Type
Pixel pitch
Viewing Angle
15.0” Diagonal
304.1 (H) x 228.1 (V) mm
a-si TFT active matrix
0.297 (H) x 0.297 (V) mm
60/60/55/55 (L/R/U/D): min.
(Depending on the panel manufacturer, the
viewing angle may be different from this
spec.)
* Frequency Horizontal
Vertical
Display color
30 – 61 kHz
50 – 75 Hz
16,003,008 colors
Display
Resolution
Optimum Mode
Maximum Mode
1024 x 768 @ 60 Hz
1024 x 768 @ 75 Hz
Input Signal Sync
Video signal
H/V Separate, TTL, P. or N.
H/V Composite, TTL, P. or N.
Sync-on-green 0.3 Vp-p, N.
0.7 Vp-p @ 75 ohm, P.
Power Supply AC 90-264 Volt, 60 Hz / 50Hz to 12V/3A
Power
Consumption
Normal
Power Saving
25 Watt
Less than 3 W
Dimensions /
Unit Weight /
incl. Carton
Unit (WxHxD) with
Simple base:
MultiMedia base:
Pivot MM base:
Angle-Pivot base:
Wire-frame base:
Carton (WxHxD):
385.4 x 373.3 x 173 mm / 5.20Kg / 8.4Kg
385.4 x 406.2 x 179 mm / 5.95Kg / 9.15Kg
385.4 x 406.2 x 179 mm / 5.95Kg / 9.15Kg
385.4 x 431.6 x 178.9 mm / 6.6Kg / 9.8Kg
385.4 x 339.2 x 99.7 mm / 4.4Kg / 7.6Kg
500 x 260 x 457 mm
Environmental
Considerations
Operating Temperature
Operating Humidity
Storage Temperature
Storage Humidity
50 ˚F to 104 ˚F (10 ˚C to 40 ˚C)
10% to 80%
13 ˚F to 113 ˚F (-25 ˚C to 45 ˚C)
5% to 95%
Audio
Characteristics
(Available with
Multimedia
bases only)
Built-in Mic.
Audio Input
Sound Output
Frequency Response
Headphone
High Sensitivity Condenser Mic. (mono)
L/R Stereo Phone Jack, 0.5 Vrms
1.0 W (L) + 1.0 W (R)/THD 1% at 8 ohm
80 Hz - 20 KHz (at -3dB)
Max 50 mW output (3.5 – pi jack)
Appendix
* Referring to Standard signal modes, page 26.
