Display Modes
If the signal from the system equals to the standard signal mode, the screen is adjusted auto-
matically. If the signal from the system doesn't equal to the standard signal mode, adjust the
mode with referring to the Videocard user guide because the screen might not display or only
the power LED might be on. For the display modes listed below, the screen image has been
optimized during manufacture.
Table 9. Preset timing modes
Display Mode
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(H/V)
VGA, 640 x 350 31.47 70.00 25.175 +/–
VGA, 720 x 400 31.47 70.00 28.322 –/+
VGA, 640 x 480 31.47 60.00 25.175 –/–
VGA, 640 x 480 37.50 75.00 31.500 –/–
Mac. 640 x 480 35.00 66.67 30.240 –/–
SVGA, 800 x 600 35.16 56.20 36.000 +, –/+, –
SVGA, 800 x 600 37.88 60.30 40.000 +/+
SVGA, 800 x 600 46.875 75.00 49.500 +/+
Mac. 832 x 624 49.73 75.00 57.284 –/–
XGA, 1024 x 768 48.36 60.00 65.000 –/–
XGA, 1024 x 768 56.48 70.00 75.000 –/–
XGA, 1024 x 768 60.02 75.00 78.750 +/+
