24
Specifications
Table 3. Specifications
Picture Tube
700IFT
: 43.0 cm (17") Full square type [40.6 cm(16”) Viewable]
900IFT
: 48.2 cm (19") Full square type [45.8 cm(18”) Viewable]
Flat face, 90° Deflection
Dot pitch : 0.20 (Horizontal) / 0.24 (Diagonal)
Anti-reflection coating with anti-electrostatic properties
Medium-short persistence phosphor
Synchronization Horizontal: 30 kHz to 96 kHz (Automatic)
Vertical: 50 Hz to 160 Hz (Automatic)
Display Colors Unlimited Colors
Maximum Resolution Horizontal: 1600 Dots
Vertical: 1200 Lines
Active Display Horizontal:
700IFT
: 312 ± 3 mm (12.28" ± 0.12”)
900IFT
: 352 ± 3 mm (13.38" ± 0.12”)
Vertical:
700IFT
: 234 ± 3 mm ( 9.12" ± 0.12”)
900IFT
: 264 ± 3 mm (10.39" ± 0.12”)
(Active display size is dependent upon signal timing and image size selection.)
Input Signal, Terminated Video signal: Analog video 0.7 Vpp positive at 75
Ω
Separate sync.: TTL Level, positive or negative
Composite sync.: TTL Level, positive or negative
Sync-on-green: Composite sync 0.3 Vpp negative
(Video 0.7 Vpp positive)
Maximum Pixel Clock 205 MHz
Power Supply AC 100-240 Volt ± 10%, 60 Hz/50 Hz ± 3 Hz
Power Consumption 130 Watt (Maximum)
Dimensions/Weight
(W x D x H)
Unit:
700IFT
: 415 x 418 x 438 mm; 18.8 kg (16.3 x 16.4 x17.2 in; 41.5 lbs)
900IFT
: 468 x 466 x 483 mm; 23.5 kg (18,4 x 18.3 x 19.0 in; 51.8 Ibs)
Carton:
700IFT
: 535 x 635 x 555 mm; 22.1 kg (21.0 x 25.0 x 21.8 in; 51.8lbs)
900IFT
: 572 x 656 x 580 mm; 27.8 kg (22.5 x 25.8 x 22.8 in; 61.3lbs)
(All measurements approximate)
Environmental Consider-
ations
Operating Temperature : 32
°
F to 104
°
F (0
°
C to 40
°
C)
Humidity : 10% to 80%
Storage Temperature : -4
°
F to 113
°
F(-20
°
C to 45
°
C)
Humidity : 5% to 95%
NOTE: Design and specifications are subject to change without prior notice.
Appendix
