3-2 Using the Product
3-2 Viewing the Control panel
NUMBER ICON DESCRIPTION
Power Indicator This light is lit when operating normally, and blinks once when your adjustments are
saved.
For more information on the power-saving function, refer to the power saving
function in More Information. When not using the product for a long time,
unplugging the power cord is recommended to minimize power consumption.
Speaker -
Toggles between all the available input sources. In the on-screen menu, use this but-
ton as you would use the [ ] button on the remote control.
Press this button to view the On Screen Display (OSD).
This button is also used to exit the OSD or to return to a higher-level OSD menu.
Moves from one menu item to another horizontally or adjusts selected menu values.
Adjusts the audio volume.
Use these buttons to navigate the menu or to adjust a value in the OSD.
Press to change channels in <TV> mode.
Press this button to turn the product on or off.
