More Information 6-1
6-1-2. B2230HD / B2330HD / B2430HD
Design and specifications are subject to change without prior notice.
Class B (Information Communication equipment for residential use)
This device is registered for EMC requirements for home use (Class B). It can be used in all areas. (Class B equipment
emits less electromagnetic waves than Class A equipment.)
MODEL NAME B2230HD B2330HD B2430HD
LCD Panel Screen Size 21.53 inches (54 cm) 23 inches (58 cm) 24 inches (61 cm)
Display Area 476.64 mm (H) x 268.11
mm (V)
509.76 mm (H) X 286.74
mm (V)
531.36 mm (H) X 298.89
mm (V)
Pixel Pitch 0.24825 mm (H) x
0.24825 mm (V)
0.2655 mm (H) x 0.2655
mm (V)
0.27675 mm (H) x
0.27675 mm (V)
Synchroniza-
tion
Horizontal Frequency 30 ~ 81 kHz
Vertical Frequency 56 ~ 75 Hz
Colour 16.7 M
Resolution Optimal Resolution 1920 x 1080 @ 60 Hz
Maximum Resolution 1920 x 1080 @ 60 Hz
Input Signal, Terminated
Analogue(D-Sub port), Digital DVI(HDMI port)
0.7 Vp-p ± 5 %
Separate Type H/V Sync, Composite
TTL Level (V high ≥ 2.0 V, V low ≤ 0.8 V)
Maximum Pixel Clock 148.500 MHz (Analogue, Digital)
Power Supply This product supports 100 – 240 V. Since the standard voltage may differ from
country to country, please check the label on the back of the product.
Dimension (Width x Height x Depth) /
Weight
523.8 x 350.6 x 67.8 mm
(20.6 x 13.8 x 2.7 inches)
(Without Stand) / 4.66 kg
(10.3 Ibs)
523.8 x 416.7 x 197.0 mm
(20.6 x 16.4 x 7.8 inches)
(With Stand) / 4.91 kg
(10.9 Ibs)
560.4 x 370.0 x 67.9 mm
(22.0 x 14.6 x 2.7 inches)
(Without Stand) / 5.15 kg
(11.4 Ibs)
560.4 x 436.7 x 197.0 mm
(22.0 x 17.2 x 7.8 inches)
(With Stand) / 5.5 kg
(12.1 Ibs)
582.0 x 381.8 x 67.9 mm
(22.9 x 15.0 x 2.7 inches)
(Without Stand) / 5.45 kg
(12.0 Ibs)
582.0 x 448.0 x 197.0 mm
(22.9 x 17.6 x 7.8 inches)
(With Stand) / 5.8 kg
(12.8 Ibs)
VESA Mounting Interface 75 mm x 75 mm (2.95 inches x 2.95 inches)
Environmental
considerations
Operating Temperature : 50°F ~ 104°F (10°C ~ 40°C)
Humidity : 10 % ~ 80 %, non-condensing
Storage Temperature : -4°F ~ 113°F (-20°C ~ 45°C)
Humidity : 5 % ~ 95 %, non-condensing
Tilt 0° ~ 20° (±1°)
