PCB Diagram
104 Samsung Electronics
No.Local Function Description
1 CN201 DOWNLOAD YDW200-20 BLK
2 CN202 EEPROM B7P-MQ WHT
3CN153 SMPS DC15V SMW250-03 RED
4 CN207SUB PBA SMW200-10 BLK
5 CN901 BLDC MO TOR YW396-06V WHT
6 CN152 SMPS DC12V SMW250-03 BL U
7 CN246QUIET_SW SMW250-02 RED
8 CN551 DOWNLOAD-INV YDAW200-20 BLK
9 CN401 COMP UYTR250
10 CN402 COMP VYTR250
11 CN403 COMP W YTR250
12 CN206SUB PBA SMW200-10 WHT
13 CN204 DRED SMW250-05 WHT
14 CN051 REACTOR YTR250
15 CN052 REACTOR YTR250
16 CN150 SMPS POWERYW396-03AV BLK
17 CN002 AC POWERYTR250
18 CN003 EARTH GP881205
19 CN001 AC POWERYT
R250
20 CN241HOTGAS YW396-03AV RED
21 CN030 4WAY YW396-03AV WHT
22 CN243 A2A VALVE YW396-03AV YEL
23 CN242 BASE HEATERYW396-03AV BL U
24 CN301 COMM YW396-02V RED
25 CN205 SUB PBA SMW200-05 BLK
26 CN251 OUT/DISCHARGE/COND/OLP SMA W200-08 WHT
27 CN245 SUCTION S
MA W250-02 WHT
28 CN252 WATER SMAW250-04 YEL
29 CN702 EEV SMW250-06 BL U
30 CN801 LOW PRESSURE SENSOR B04B-XAEK-1 BLU
31 CN809 HIGH PRESSURE SENSOR B04B-XARK-1 RED
