Disassembly and Reassembly
Samsung Electronics 27
No Parts Procedure Remark
4 Expansion Vessle 1) Remove the tube of the expansion vessel
and the backup heater by adjustable wrench.
(Use adjustable wrench-150kgf·cm)
Use the Torque Wrench when you
assemble it.
2) Remove 2 screws. (Use + Screw Driver)
3) After removing the nut. Pull the bracket out.
4) Pull the expansion vessel up, out.
5 Plate Heat
Exchanger
1) Remove 4 insulations.
To Next Page
