2-2 Product Specifications
MODEL
INDOOR UNIT TH026EAV TH035EAV TH052EAV TH060EAV
OUTDOOR UNIT UH026EAV UH035EAV UH052EAV UH060EAV
Capacity
Cooling
BTU/h 9,000 12,000 18,000 21,000
W 2,600 3,500 4,700 5,800
Heating
BTU/h 11,000 14,000 21,000 25,000
W 3,300 4,000 5,500 7,000
Power Supply
Φ/V/Hz
1/220-240/50
Power Input
Cooling W 710 1,090 1,670 2,060
Heating W 885 1,105 1,710 2,180
Running
Current
Cooling A 3.4 5.1 7.6 8.8
Heating A 4.2 5.2 8.1 10.5
Indoor Unit
Fan Speed
Hi r.p.m 710 700 720 820
Mid r.p.m 600 600 680 780
Low r.p.m 490 500 630 730
Air Flow
Hi m
3
/min 12 12 13 14
Mid m
3
/min 10 10 12 13
Low m
3
/min 9 9 11 12
Noise Level(Sound Pressure)
dB(A) 43 44 47 48
Heat Exchanger
Type Slit
RowxStagesxFin pitch
2x10x1.4mm
Fan Type Turbo
Demensions
H mm 260
W mm 575
D mm 575
Weight Net/Gross kg 16.0/18.5
Outdoor Unit
Fan Speed
Hi r.p.m 850 850 800 830
Low r.p.m 600 600 750 600
Noise Level(Sound Pressure)
dB(A) 51 53 58 60
Fan Type Propeller
Compressor
Type Inverter
Model G4C090LU2ER G4C090LU2ER G8T200FU1EW G8T260FU1EW
Motor Output
kW 0.853 0.853 2.0 2.4
Protection External
Refrigerant
Type R410A
Charge g 1,000 1,000 1,300 1,500
Adding Charge
g/m 15 15 20 15
Control Expansion Valve
Type W-Slit
RowxStagesxFin pitch
2x24x1.5mm 2x24x1.5mm 2x28x1.5mm 2x36x1.5mm
Demensions
H mm 790 790 638 793
W mm 548 548 880 880
D mm 285 285 310 310
Weight Net/Gross kg 35.5/38 35.5/38 61/64 66/69
Piping
Pipe O.D Size
Liquid mm(inch) 6.35(1/4”) 6.35(1/4”) 6.35(1/4”) 6.35(1/4”)
Gas mm(inch) 9.52(3/8”) 9.52(3/8”) 12.7(1/2”) 15.88(5/8”)
Connection Method
Flare
Between
Height m Max.12 Max.15
Pipe Lengh
m Max.20 Max.30
