5. Exploded View & Part List
5-2. UE19C4000PW Parts List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UE19C4000PWXXH
0.1
S001A BN90-02602A ASSY STAND;UC4000 22 1 SNA
..2
MASB1 BN96-10168C ASSY STAND P-BODY;UC4000 22,PC 1 SA
..2
SB04A BN96-11163D ASSY STAND P-BASE;UC4000 19/22,PC+ABS,V0 1 SA
0.1
BN90-02621B ASSY COVER FRONT;UC4000 19 1 SNA
..2
F001A BN96-13378B ASSY COVER P-FRONT;UC4000 19,EO,PC+PC,V2 1 SA
0.1
R001A BN90-02622B ASSY COVER REAR;UC4000 19 1 SNA
..2
SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 9 SA
..2
R001A BN96-13379B ASSY COVER P-REAR;UC4000 19,EO,PCM,BKN-P 1 SA
0.1
M0017 BN91-05038D ASSY CHASSIS;UE19C4000PWXXC 1 SNA
..2
M0014 BN94-02758D ASSY PCB MAIN;UE19C4000PWXXC,BN94-02758C 1 SA
...3
0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 SNA
...3
3701-001698 CONNECTOR-DSUB;15P,3ROW,FEMALE,ANGLE,NI 1 SA
...3
3709-001603 CONNECTOR-CARD SLOT;68P(U/SLIM 60mm) W/L 1 SA
...3
3711-007302 HEADER-BOARD TO BOARD;BOX,18P,2R,2mm,ANG 1 SA
...3
JA330 3722-002844 JACK-PHONE;1/7P,NI,LAUREL-GREEN,ANGLE 1 SA
...3
JA330 3722-002845 JACK-PHONE;1/7P,NI,YELLOW,ANGLE 1 SA
...3
JA330 3722-002846 JACK-PHONE;1/6,NI,BLACK,ANGLE 2 SNA
...3
ET01 BN40-00172A TUNER;DTOS40CVH081A,DVB-T/C,164CH,38.9MH 1 SA
...3
HDP01 BN61-06644A HOLDER-PCB;LC750,NYNOL66,V0 1 SNA
...3
T0066 BN62-00042A HEAT SINK-ES;30*30*5,Ceramic,T1.5,TAPE 1 SNA
...3
BN96-14859D ASSY BRACKET P-AV;UC4000 19,SO(DTV),PCM, 1 SNA
....4
T0073 AA63-01332A GASKET-EMI;42P5,Conductive Fabric,1.5mm, 1 SNA
....4
CB01 BN61-06208A BRACKET-AV;UC 4000,PCM,0.5,BKN-P824,EO 1 SNA
....4
M0131 BN63-03888A GASKET;LS24HUC,Polyester+Cu+Ni+Hotmelt,1 1 SNA
...3
BN97-04055D ASSY SMD;UE19C4000PWXXC,BN94-02758D 1 SNA
....4
0202-001767 SOLDER-CREAM;LST-5710,D20~38,42Sn/57Bi/1 1.69 SNA
....4
DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 14 SA
....4
D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 2 SA
....4
0403-001164 DIODE-ZENER;MMSZ5232B,5.32-5.88V,500MW,S 1 SA
....4
0403-001180 DIODE-ZENER;BZX84C6V2,5.8-6.6V,350mW,SOT 1 SA
....4
0403-001783 DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO 15 SNA
....4
D0254 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 1 SA
....4
T0139 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 1 SA
....4
T0139 0406-001271 DIODE-TVS;RCLAMP0524P,6/-/-V,150W,SLP251 4 SNA
....4
SD3 0407-000114 DIODE-SWITCHING;KDS184,80V,100mA,SOT-23, 2 SNA
....4
KQ1 0501-000279 TR-SMALL SIGNAL;KSA1182-Y,PNP,150mW,SOT- 1 SA
....4
Q101 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 12 SA
....4
CEQ2 0505-000110 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 5 SA
....4
Q409 0505-000274 FET-SILICON;AO4435L,P,-30V,-11A,0.014ohm 1 SNA
....4
IC104 0801-002630 IC-CMOS LOGIC;74AHCT1G08,2-INPUT AND GAT 1 SA
....4
ND51C2 0801-002780 IC-CMOS LOGIC;74LVC1G17,SCHMITT-TRIGGER 1 SA
....4
IC104 0801-003330 IC-CMOS LOGIC;Octal buffer,DQFN,20P,4.5x 3 SA
....4
IC104 0802-001012 IC-CMOS LOGIC;74LCX245,TRANSCEIVER,DQFN, 1 SNA
....4
IC106 1001-001573 IC-VIDEO SWITCH;SiI9287BCNUTR,QFN,72P,10 1 SNA
....4
1006-001474 IC-LINE DRIVER;DRV604PWP,HPSSOP,28P,9.8x 1 SA
....4
IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8,SOP,8P,5x4mm 2 SA
....4
T0124 1201-002992 IC-POWER AMP;STA369BWS,PSSO,36P,10.3x7.5 1 SA
