Samsung UE19C4000PW - Page 72

5-3
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4
T0087 1203-001815 IC-POSI.FIXED REG.;78M09,TO-252,3P,PLAST 1 SA
....4
T0087 1203-002835 IC-POSI.FIXED REG.;KIA7805AF,DPAK,3P,6.6 1 SA
....4
T0087 1203-002898 IC-POSI.FIXED REG.;G950T45R,T0-252,3P,6. 1 SA
....4
1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 SA
....4
1203-005538 IC-DC/DC CONVERTER;AOZ1021HAIL,SOP,8P,4. 1 SA
....4
1203-006013 IC-DC/DC CONVERTER;AOZ1031AI,SO-8,8P,4.9 1 SA
....4
1203-006017 IC-VOL. DETECTOR;RT9824GJ8,TSOT23,8P,2.9 1 SA
....4
T0087 1203-006135 IC-POSI.FIXED REG.;AP1117D-33-GZ-13-89,T 1 SA
....4
T0087 1203-006136 IC-POSI.FIXED REG.;AP1117D-18-GZ-13-89,T 1 SA
....4
IC012 1203-006138 IC-POSI.ADJUST REG.;AP1117DGZ-13-89,TO-2 1 SA
....4
1203-006142 IC-DC/DC CONVERTER;BD8924G,5P,2.9x1.6x1. 1 SA
....4
1203-006288 IC-VOL. DETECTOR;RT9818B-18GV,SOT-23-3,3 1 SA
....4
1203-006337 IC-POSI.FIXED REG.;G9091-330T11U,SOT-23- 1 SA
....4
1204-003088 IC-DEMODULATOR;DRX39XYK,PQFN,64P,9x9x0.8 1 SA
....4
1204-003096 IC-VIDEO DECODER;HIDTVPRO-SX,PBGA,580P,P 1 SA
....4
1205-003201 IC-BUS SWITCH;TC7WB125FK,SSOP,8P,2x2.3mm 2 SA
....4
1205-003479 IC-SWITCH;TPS2051BDBVR,SOT-23,5P,2.9x1.6 1 SA
....4
1205-003733 IC-SWITCH;AP2191MPG-13,MSOP-8L-EP,8P,2.9 1 SA
....4
1405-001185 VARISTOR;24Vdc,1.6x0.8x0.36mm,TP 1 SA
....4
1405-001271 VARISTOR;20Vdc,5A,1.0x0.5x0.6mm,TP 22 SA
....4
J914 2007-000029 R-CHIP;0ohm,5%,1/8W,TP,2012 1 SC
....4
KAR21 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 SA
....4
PR6 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 4 SA
....4
R105 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 29 SA
....4
AR49 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 5 SA
....4
MR306 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 14 SA
....4
R319 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 46 SNA
....4
2007-000146 R-CHIP;6.8Kohm,5%,1/16W,TP,1005 2 SA
....4
R104 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 49 SA
....4
R102 2007-000149 R-CHIP;12Kohm,5%,1/16W,TP,1005 6 SA
....4
HDR2 2007-000151 R-CHIP;15Kohm,5%,1/16W,TP,1005 1 SNA
....4
MR36 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 7 SNA
....4
AR43 2007-000155 R-CHIP;27Kohm,5%,1/16W,TP,1005 2 SNA
....4
MR13 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 6 SA
....4
R123 2007-000159 R-CHIP;56Kohm,5%,1/16W,TP,1005 2 SNA
....4
DR39 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 SA
....4
MR16 2007-000168 R-CHIP;470Kohm,5%,1/16W,TP,1005 1 SNA
....4
R509 2007-000170 R-CHIP;1Mohm,5%,1/16W,TP,1005 1 SA
....4
R111 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 17 SA
....4
HDR17 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 10 SA
....4
R338 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 14 SA
....4
UR23 2007-000174 R-CHIP;47ohm,5%,1/16W,TP,1005 2 SA
....4
R726 2007-000695 R-CHIP;3.3ohm,5%,1/10W,TP,1608 1 SNA
....4
R124 2007-000775 R-CHIP;33Kohm,5%,1/16W,TP,1005 3 SA
....4
HR3 2007-000903 R-CHIP;430ohm,1%,1/10W,TP,1608 1 SA
....4
DR37 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 SA
....4
2007-001285 R-CHIP;5.6ohm,5%,1/16W,TP,1005 2 SA
....4
OTR1 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 9 SA
....4
DR43 2007-001298 R-CHIP;51ohm,5%,1/16W,TP,1005 1 SA
....4
R326 2007-001325 R-CHIP;3.3Kohm,5%,1/16W,TP,1005 9 SA
....4
2007-002768 R-CHIP;6.2Kohm,1%,1/10W,TP,1608 1 SA
