Samsung UE19C4000PW - Page 73

5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4
MR316 2007-002796 R-CHIP;510ohm,5%,1/16W,TP,1005 1 SA
....4
PR24 2007-002970 R-CHIP;56ohm,5%,1/16W,TP,1005 2 SA
....4
TR30 2007-007009 R-CHIP;75ohm,5%,1/16W,TP,1005 13 SA
....4
2007-007134 R-CHIP;39Kohm,1%,1/16W,TP,1005 1 SA
....4
2007-007135 R-CHIP;18Kohm,1%,1/16W,TP,1005 1 SNA
....4
DR4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 2 SA
....4
2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 8 SA
....4
2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 1 SNA
....4
2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 2 SA
....4
2007-007316 R-CHIP;3.3Kohm,1%,1/16W,TP,1005 1 SNA
....4
2007-007317 R-CHIP;2.2Kohm,1%,1/16W,TP,1005 1 SA
....4
2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 10 SNA
....4
2007-007334 R-CHIP;200Kohm,1%,1/16W,TP,1005 2 SA
....4
MR11 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 11 SA
....4
2007-008134 R-CHIP;12.4Kohm,1%,1/16W,TP,1005 1 SC
....4
2007-008275 R-CHIP;30Kohm,1%,1/16W,TP,1005 1 SNA
....4
2007-008563 R-CHIP;270ohm,1%,1/16W,TP,1005 1 SA
....4
2007-008593 R-CHIP;750ohm,1%,1/16W,TP,1005 1 SA
....4
2007-008649 R-CHIP;220ohm,1%,1/16W,TP,1005 3 SNA
....4
ZRN10 2011-001261 R-NETWORK;33ohm,5%,1/16W,L,CHIP,8P,TP,2. 6 SA
....4
DAR09 2011-001262 R-NETWORK;22ohm,5%,1/16W,L,CHIP,8P,TP,2. 5 SA
....4
2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1010 6 SA
....4
DRP9 2011-001474 R-NETWORK;47ohm,5%,1/16W,L,CHIP,8P,TP,2. 1 SA
....4
2011-001519 R-NETWORK;33OHM,5%,1/16W,L,CHIP,4P,TP,1. 2 SA
....4
2011-001527 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,4P,TP, 7 SNA
....4
2011-001589 R-NETWORK;0ohm,5%,1/16W,L,CHIP-V,4P,TP,1 8 SNA
....4
DC30 2203-000138 C-CER,CHIP;1.5nF,10%,50V,X7R,TP,1005,- 2 SA
....4
PC43 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 4 SA
....4
MC302 2203-000425 C-CER,CHIP;.018nF,5%,50V,C0G,TP,1005 2 SA
....4
C254 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 13 SNA
....4
AC139 2203-000491 C-CER,CHIP;2.2nF,10%,50V,X7R,1608 2 SNA
....4
MC9 2203-000627 C-CER,CHIP;.022nF,5%,50V,C0G,TP,1005 2 SNA
....4
DC374 2203-000659 C-CER,CHIP;0.27nF,5%,50V,C0G,1608 1 SA
....4
AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,1005 1 SA
....4
DC25 2203-000812 C-CER,CHIP;.033nF,5%,50V,C0G,TP,1005 11 SNA
....4
CK40B 2203-000838 C-CER,CHIP;.39nF,5%,50V,C0G,1608 2 SNA
....4
KFC6 2203-000872 C-CER,CHIP;0.0030nF,0.25pF,50V,C0G,1608 2 SNA
....4
HDC5 2203-001072 C-CER,CHIP;0.056nF,5%,50V,NP0,1005 4 SA
....4
C101 2203-001124 C-CER,CHIP;.68nF,10%,50V,X7R,1005 1 SA
....4
DC87 2203-001153 C-CER,CHIP;.068nF,5%,50V,NP0,1005 2 SA
....4
AD480 2203-001428 C-CER,CHIP;470nF,10%,50V,X7R,TP,2012 2 SNA
....4
AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,1005 15 SNA
....4
AD480 2203-002525 C-CER,CHIP;0.56nF,10%,50V,X7R,TP,1005 6 SNA
....4
C711 2203-002982 C-CER,CHIP;6.8nF,10%,50V,X7R,1005 1 SA
....4
AAC1 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 7 SA
....4
AD480 2203-005511 C-CER,CHIP;27nF,10%,10V,X7R,TP,1005 1 SA
....4
AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,1005 1 SNA
....4
AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,TP,1005 3 SNA
....4
C102 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,TP,1005 114 SA
....4
JC10 2203-006324 C-CER,CHIP;2200nF,10%,10V,X5R,1608 2 SA
....4
AD480 2203-006336 C-CER,CHIP;10000nF,10%,25V,X5R,3216 25 SA
