5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....4
C125
2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 37 SA
....4
HE4
2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,2012 3 SA
....4
AD480
2203-006841 C-CER,CHIP;1000nF,10%,16V,X5R,TP,1005 26 SNA
....4
AD480
2203-006992 C-CER,CHIP;0.33nF,5%,50V,C0G,TP,1005 2 SNA
....4
AD480
2203-007233 C-CER,CHIP;22000nF,10%,16V,X5R,TP,3216 1 SA
....4
T0052
2703-000158 INDUCTOR-SMD;1uH,10%,2012 3 SA
....4
T0052
2703-000296 INDUCTOR-SMD;680nH,10%,1608 1 SA
....4
VL6
2703-000398 INDUCTOR-SMD;10uH,10%,3225 3 SA
....4
T0052
2703-001239 INDUCTOR-SMD;3.3uH,10%,1608 3 SA
....4
L607
2703-001254 INDUCTOR-SMD;1.8uH,10%,2012 1 SA
....4
T0052
2703-003149 INDUCTOR-SMD;2.2uH,20%,5050 2 SA
....4
2703-003890 INDUCTOR-SMD;47uH,10%,3225 1 SA
....4
X202
2801-003326 CRYSTAL-SMD;24MHz,30ppm,28-ABX,20pF,50oh 1 SA
....4
X202
2801-004004 CRYSTAL-SMD;20.25MHz,20ppm,28-AAN,13pF,2 1 SA
....4
F103
2901-001506 FILTER-EMI SMD;5V,0.13A,0pF,2x1x0.5mm,TP 2 SA
....4
T0568
3301-001186 BEAD-SMD;600ohm,3216,2500mA,TP,553ohm/93 5 SA
....4
T0568
3301-001236 BEAD-SMD;60ohm,1608 5 SNA
....4
T0568
3301-002039 BEAD-SMD;26ohm,1608,TP 40 SA
....4
3701-001293 CONNECTOR-HDMI;19P,2R,FEMALE,SMD-A,AU 2 SA
....4
CN906
3707-001095 CONNECTOR-OPTICAL;SMD-A(Ultra Slim),SPDI 1 SA
....4
AC510
3708-001150 CONNECTOR-FPC/FFC/PIC;30P,1mm,SMD-A,SN,Y 1 SA
....4
3710-002276 SOCKET-INTERFACE;24P,1R,0.5mm,SMD-A,AU,B 1 SA
....4
HB01A
3711-005601 HEADER-BOARD TO CABLE;BOX,8P,1R,2mm,SMD- 1 SNA
....4
HB01A
3711-007336 HEADER-BOARD TO CABLE;B0X,4P,1R,2.5mm,SM 1 SA
....4
3722-003044 JACK-USB;4P/1C,NI,BLK,SMD-A,A-TYPE 1 SA
....4
BN41-01379A PCB MAIN;SX1 4000 DVB,FR-4,4,1.0,1.2T,19 1 SNA
....4
BN97-04023A ASSY MICOM-MAIN;N82A,2009.11.10,T-TDT5DE 1 SNA
.....5
1107-001940 IC-NAND FLASH;KFG1G16U2D-HIB6,1Gbit,64Mx 1 SNA
....4
BN97-04024A ASSY MICOM-SUB;N82A,2009.11.10,T-TDT5DEU 1 SNA
.....5
1107-001938 IC-FLASH MEMORY;W25X40BVSSIG,4Mbit,SOP,8 1 SNA
....4
1103-001487 IC-EEPROM;AT24C256C-SSHL-T,256Kbit,32Kx8 1 SA
....4
1105-002153 IC-DDR2 SDRAM;K4T1G164QF-BCF8,DDR2,1Gbit 2 SNA
...3
BN97-04098A ASSY CI PLUS;BN46-00025A,LC5F,SX1 platfo 1 SNA
....4
BN46-00025A KEY CODE-CI PLUS KEY;CI PLUS KEY,TCTC,SE 1 SNA
...3
T0066
BP62-00047A HEAT SINK-ES;DLP,A6063S,T2.5,13,13,TAPE 2 SNA
0.1
BN91-05039A ASSY SHIELD;UE19C4000PFXXC 1 SNA
..2
CIS1
0203-001586 TAPE-FILAMENT;#893,0.15,30,55 0.1 SNA
..2
T0081
6001-000321 SCREW-MACHINE;FH,+,M3,L10,NI PLT,SWRCH18 2 SA
..2
M0081
6003-000115 SCREW-TAPTYPE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 SNA
..2
W392
6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 SA
..2
M2893
BN39-01267B LEAD CONNECTOR;LA32C450,UL 2651 #26,18P, 1 SA
..2
P001A
BN44-00345A DC VSS-LED TV PD BD;PD19AF0E_ZSM,PSLF500 1 SA
..2
M0131
BN63-00209A GASKET;RS24NS,CONDUCTIVE FAB,4mm,10mm,30 4 SNA
..2
T0531
BN63-06768A COVER-BOTTOM;UC4K-19,HIPS,V0,BK500,BLK 1 SNA
..2
CCMM1
BN73-00264A SILICON/RUBBER;LE32C530F1WXXC,SILICON+PO 1 SNA
..2
BN73-00283A SILICON/RUBBER-GAPPAD;UA32C5000,SILICON+ 1 SNA
..2
BN74-00111A TAPE;DTS-204K,15mm*50M,BLACK 0.05 SNA
..2
FL06
BN96-12447X ASSY CABLE P-FFC;UE19C4000,FFC,0.5mm,105 1 SA
..2
M0525
BN96-13413A ASSY COVER P-GUIDE STAND;UC4000 19/22,PC 1 SA
..2
CB06A
BN96-14673A ASSY BRACKET P-PANEL;UC4000 19,SECC,T1.0 1 SNA
..2
SCREW
6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 5 SA
