SYSTEM AIR CONDITIONER
Basic : DH094EAMC AQV24AWAX
Model
: DH070EAS UH070EAS
DH052EAS UH052EAS
Model Code : DH070EAS UH070EAS
Model Code : DH052EAS UH052EAS
AIR CONDITIONER THE FEATURE OF PRODUCT
Easier installation
: Silm size
Built-in duct type
High performance & Energy saving
Long piping (Length & Height)
: Max. 30m Long & 15m Height
Long ambient operation (In low temp.)
: Up to -15ºC(Heating) & Up to -10ºC(Cooling)
Eco-friendly product
(Lead-free, RoHS, WEEE)
UH052/070EAS
DH052/070EAS
Refer to the service manual in the GSPN(see the rear cover) for the more information.

Table of Contents

Questions and Answers

  • M
    Mr. Kevin AllenSep 23, 2025
    What to do if my Samsung Air Conditioner displays Indoor unit Eva In sensor (open/short)?
    • A
      Alicia SalinasSep 23, 2025
      If your Samsung Air Conditioner displays an Indoor unit Eva In sensor (open/short), check the indoor unit drainage pipe sensor and the indoor PCB connector CN21 (white).
  • R
    rosechristinaAug 23, 2025
    What to do if my Samsung UH052EAS showing outdoor temperature sensor error?
    • T
      Tammy BrownAug 25, 2025
      If your Samsung Air Conditioner displays an outdoor temperature sensor error, check the connection status of the sensor, its location, and the resistance values of the sensor.
  • S
    sarabuckAug 25, 2025
    What to do if my Samsung UH052EAS displays a gas leakage error?
    • G
      gmasonAug 26, 2025
      If your Samsung Air Conditioner displays a gas leakage error, verify that the refrigerant is filled and check the indoor EVA sensor.
  • C
    cynthiaclarkAug 27, 2025
    What to do if my Samsung UH052EAS showing outdoor fan 1 error?
    • D
      Dr. Jared WashingtonAug 27, 2025
      If your Samsung Air Conditioner displays an outdoor fan 1 error, check the input power connection status, the connection between the motor and PCB in the outdoor unit, and the fuse of the indoor/outdoor units.
  • J
    Jody WilliamsAug 27, 2025
    What to do if my Samsung Air Conditioner showing outdoor fan 2 error?
    • K
      kenneth74Aug 27, 2025
      If your Samsung Air Conditioner displays an outdoor fan 2 error, check the connection status of input power, the connection status of the motor and outdoor PCB, and the fuse of the indoor/outdoor unit.
  • C
    Carolyn JenningsSep 16, 2025
    What to do if my Samsung UH052EAS Air Conditioner displays a '[inverter] OTP error'?
    • M
      Matthew RussoSep 16, 2025
      If your Samsung Air Conditioner displays an inverter OTP error, check if the PCB operates normally.
  • M
    manningjoshuaSep 13, 2025
    What to do if my Samsung UH052EAS Air Conditioner displays a 'Dismount of indoor unit Eva In sensor' error?
    • A
      Angela ByrdSep 13, 2025
      If your Samsung Air Conditioner displays a 'Dismount of indoor unit Eva In sensor' error, check if the drainage pipe has been dismounted.
  • K
    Kendra HuertaSep 15, 2025
    What to do if my Samsung Air Conditioner displays a '[inverter] Current sensor error'?
    • J
      Joshua HooverSep 15, 2025
      If your Samsung Air Conditioner displays an inverter current sensor error, check if the PCB operates normally.
  • J
    Jimmy HansonSep 6, 2025
    What to do if my Samsung UH052EAS Air Conditioner displays a '1min. Time out Comm. (Display Board : Onboard : Indoor ? Outdoor)' error?
    • P
      Paul WalkerSep 6, 2025
      If your Samsung Air Conditioner displays a 1-minute time out communication error, check the indoor unit connection and the indoor unit option.
  • M
    Melissa MartinSep 3, 2025
    What to do if my Samsung UH052EAS displays a 'Non-connection error of indoor and outdoor Communication wire (connected to the power terminal)'?
    • B
      Barbara CraigSep 3, 2025
      If your Samsung Air Conditioner displays a non-connection error of indoor and outdoor communication wire connected to the power terminal, check the status of the power connection and the connection status of the communication line.

Summary

System Air Conditioner Overview

Key Product Features

Lists key features of the air conditioner, including easy installation, high performance, long piping, and eco-friendly design.

Air Conditioner Precautions

Installation Safety Guidelines

Guidelines for safe and proper installation of the air conditioner.

Product Specifications

Detailed Technical Specifications

Technical specifications and performance data for the air conditioner models.

Disassembly and Reassembly

Indoor Unit Disassembly Procedure

Step-by-step instructions for disassembling the indoor unit.

Wiring Diagram

Indoor Unit Wiring Diagram

Electrical wiring diagram for the indoor unit.

PCB Diagram

Indoor PCB Diagram

Layout and component identification for the indoor unit's PCB.

Operating Instructions

Wireless Remote Control Guide

Explanation of buttons and display elements on the wireless remote controller.

Troubleshooting Guide

Initial Troubleshooting Checks

Initial checks and common issues before detailed troubleshooting.

Fault Diagnosis by Symptom

Step-by-step guide to diagnose faults based on observed symptoms.

Reference Sheet

Installation Guide

Procedures and guidelines for installing the air conditioner.

Samsung UH052EAS Specifications

General IconGeneral
BrandSamsung
ModelUH052EAS
CategoryAir Conditioner
LanguageEnglish
