10_ maintain tools and filter
maintain tools and filter
Pipe
• Adjust the length of the telescopic pipe by sliding the length
control button located in the center of the telescopic pipe back
and forth.
• Tocheckforblockages,separatethetelescopicpipeand
adjust to shorten.
This allows for easier removal of waste clogging the tube.
Cleaning the cyclone filter (Optional)
• It is necessary to use Cyclone Filter while cleaning.
MAINTAIN FLOOR TOOLS
2-Step brush (Optional)
• Adjust the inlet lever according to the
floor surface.
• Removewastemattercompletelyiftheinletisblocked.
1 2 3
4 5 6
Carpet cleaningFloor cleaning
