Samsung VCC7490 - Power Control

operating the cleaner _07
02 OPERATING THE CLEANER
POWER CONTROL
Body-control type (Optional)
-HOSE
To reduce suction for leaning draperies, small rugs, and
other light fabrics, pull the tap air until the hole is open.
-BODY(VOLUMETYpEONLY)
To control power level, just slide the power control
bottom right and left.
MIN = For delicate fabrics, e.g.net curtains.
MAX = For hard floors and heavily soiled carpets.
-USINGTHEBLOWER
Located on the left rear side of the cleaner.
1) Disconnect the hose from the body of the
cleaner.
2) Connect the hose clamper to the blow hole.
