To Next PageTo Next PageWhat does error 4C mean on a Samsung WD11 K64?
The 4C error on your Samsung Washer may be caused by foreign material entering the water supply valve, a disconnected water supply valve terminal, or wrongly connected warm water and rinse connectors. This error can also occur if the PCB terminal from the drain hose to the detergent drawer is not connected, or if the transparent hose is folded or torn.
What to do if my Samsung Washer displays an AC error?
The AC error on your Samsung Washer indicates that the signals between the sub and main PBAs are not being sensed due to a communication issue. You can check the connector connections between the sub and main PBAs for incorrect or loose connections. Also, you can remove the sub PBA C/Panel and check for any faulty soldering.
What to do if my Samsung WD11 K64 displays a 5C error?
The 5C error on your Samsung Washer indicates a draining issue. This can occur if the pump motor impeller is damaged, the wrong voltage is supplied, or there's a part fault. It might also be due to freezing in winter. Check if the drain hose is clogged with materials, such as rubber bands, bills, cotton, hair pins, or coins inside the drain pump assembly.
What causes the DC error on a Samsung Washer?
The DC error on your Samsung Washer may occur due to a deformation of the door hook affecting the switch contact. It can also happen if the door is pulled with excessive force or, during a boil wash, if the door is pushed open due to pressure from internal temperature changes.
What does error 3C mean on a Samsung WD11 K64 Washer?
The 3C error on your Samsung Washer can be caused by several factors: * The PBA connector terminal is not connected. * The motor spin net is not engaged. * The motor's internal coil is damaged. * The hall sensor terminal is not connected. Also, check for foreign material in the motor, motor overload, a weak motor driving check from the PBA, erroneous signals from the motor hall sensor, a disconnected IPM terminal, a DD motor cover out of place, a disconnected PCB housing terminal, or a DD motor fault. It could also be a PBA fault.
What does error 1C mean on a Samsung WD11 K64?
The 1C error on your Samsung Washer indicates a problem with the water level sensor. The part of the hose where the water level sensor is located might be damaged, clogged, or folded. Too much lubricant on the air hose insertion part, a disengaged hose, faulty internal soldering, a disengaged water level sensor terminal, or a main PBA fault could also be the cause.
What to do if Samsung WD11 K64 displays HC HC1 HC2 error?
The HC, HC1, or HC2 error on your Samsung Washer may indicate that the washing heater or drying heater is short-circuited or has a wire disconnected. It may also indicate a check of the washing heater in the tub, or if the water level sensor operates without water and the temperature sensor detects a high temperature, the washing machine turns off the input power.
What does DC1 error mean on a Samsung Washer?
The DC1 error on your Samsung Washer can occur if the door lock switch terminal is connected incorrectly or is broken. It may also happen intermittently due to an electric wire leakage or a main PCB fault.
What does error code 4C2 mean on a Samsung Washer?
The 4C2 error on your Samsung Washer can occur if the cold and warm water supply hoses are wrongly engaged, if the water temperature supplied through the dry valve during a dry cycle is sensed as higher than 70 °C, or if the water temperature is sensed as higher than 50 °C in the Wool or Lingerie courses.
Why does my Samsung WD11 K64 Washer show the OC error?
The OC error on your Samsung Washer indicates that water is being supplied continually because the water level detection is not working. This could be due to a clogged drain hose, foreign material in the water supply valve, freezing, or a degraded water level sensor.
General| Washing Capacity (kg) | 11 |
|---|---|
| Drying Capacity (kg) | 7 |
| Spin Speed | 1400 RPM |
| Energy Efficiency Class Washing | A+++ |
| Energy Efficiency Class Washing and Drying | A |
| Noise Level Spinning | 74 dB |
| Noise Level Drying | 62 dB |
| Digital Inverter Motor | Yes |
| AddWash | Yes |
| EcoBubble Technology | Yes |
Guidelines for safe operation and prevention of accidents during servicing.
Lists necessary tools and their types for disassembly and reassembly procedures.
Step-by-step visual guide for disassembling major components of the washing machine.
Lists various check modes, their causes, and relevant remarks for diagnostics.
Provides detailed corrective actions for specific error codes and troubleshooting scenarios.
