ALIGNMENT AND ADJUSTMENTS
12
Diagnostic Code Check Mode
Denition of Diagnostic Code Check Mode:
- Diagnostic Code Check Mode is to bring up the stored diagnostic codes (refere nce codes for
service technicians).
How to Enter:
- To enter the Diagnostic Code Check Mode with code “d” ashing, press the Pure Cycle key during
Service Mode.
Board Input Test Mode:
1. Activate the Service Mode rst.
2. Press the “Pure Cycle key” key to start Diagnostic Code Check Mode with Code “d” ashing.
3. To cycle through the diagnostic codes (d1,d2,d3~d9), turn the Rotary Cycle Selector in one
direction (either Clockwise or Counterclockwise).
4. Now, when turning the Rotary Selector Key in the same direction, it shows diagnostic codes
from the latest (d1).
5. When turning it in the opposite direction, it shows the diagnostic codes in the reverse order.
Ex) When it stops at d5 and turns backward, it shows from d4 down to “d”. Refer to Diagnostic
Code.
To avoid risk of electrical shock, personal injury or death; disconnect power to washer
before servicing, unless testing requires power.
WARNING
Service Mode
Pure Cycle
Start/Pause
Pressing
Signal
Diagnostic Code
Cycle No.
Before making Code
Cycle Count
