Samsung XA160T - Parts BOM List

25
5.3 Parts BOM List
Code
Name
Spec
Unit
Quantity
R2S8-22-1721
Sending box
MCTRL600-S
（
ROHS
）
PCS
Depend on
project
R2W8-27-10392
Outdoor Cabinet
960*960*100mm
PCS
R4B3-10-10013
P10 module
32X32 EMC Nova
system(ROHS)
PCS
R2J8-22-0125
3 core plug
L 1.5M
PCS
2S8-22-10025
U Disk
Control software/Setting files
PCS
R2L3-27-0104
DVI cable
L 1.5M
PCS
R2L3-27-0105
USB cable
L 1.5M
PCS
R2S8-22-1761
Receiving card
A4S
（
ROHS
）
PCS
R3C6-88-10053
Hub Board
Hub for XAT
PCS
Depend on
project
Signal input cable
Cat-5 type L
(depend on project)
PCS
Depend on
project
AC power input
cable
3*2.5m
㎡
L(depend on
project)
PCS
3D2-22-10363
AC Power
cascade cable
3*2.5m
㎡
50CM,two end
connectors
PCS
3D3-23-10101
Signal cascade
cable
Cat-5 type 60CM,two end
connectors
PCS
R2J8-42-0200
Connect plate
130*100*4.0mm
（
ROHS
）
PCS
R2J8-42-2403
Connect plate
130*50*4.0mm
（
ROHS
）
PCS
R2W8-22-0466
M10 Bowls
Six angle (stainless steel)
(ROHS)
PCS
R2W8-29-3277
Key for back door
Circle with ears
PCS
R2D8-25-10006
Power supply
GW-XSP300WV4.5 / 5V/60A
PCS
R2S9-88-0298
Air switch
NDB2-63-D10(ROHS)
PCS
R3G1-27-0048
LED package
Nation Star 2727
(M-Z2727RGBA-SH)
PCS
R2K2-22-0219
Driver IC
MBI5051B GP
MSSOP24L-150-0.635
PCS
R2A8-24-10024
Mask
Mask P10(16*16) H-5mm
ROHS
PCS
R2W8-22-1410
Screws for Mask
Black (φ2.8) ROHS
PCS
3D2-22-8474(...)
DC output cable
2.5m
㎡
2.5-40,6P3.96
80CM (UL)...
PCS
3D4-23-10040(...)
Flat cables
20P 20CM(UL)...
PCS
