Samwha DSP DSP-VIP-PL - Indication List; Line Voltage and Load Current Indication; Temperature and Power Factor Indication

Accumulated
KWH
*if a current greater than 0.2A is
loaded,KWH is accumulated every 6 min.
*possible to record 99999999 KWH
*to clear existing accumulated KWH: in
"hp-c" mode ,press "DN" under pressing
"UP" at first ,then finally make both
pressing state ,and reversely release "UP"
after releasing “DN” at first
Accumulated
working time
*if a current greater than 0.2A is loaded,
working time is accumulated in every 6
min
*range:0~6553.5 hr,next to zero
*to clear an existed value , use the way to
call initial factory default value
preset time to
make alarm for
working time
*indicating a trip event number of main
contactor
*range:1~65535, next to zero
*to clear existing accumulated number in
“Alt” mode :refer a case of KWH
Trip
number/main
contactor
*indicating trip number of main contactor
*range:1~65535, next to zero
*to clear existing accumulated KWH:refer
a case of KWH
Load factor by
bar graph
*calculating % as followed.
[actual load curr./preset curr.]*100[%] or
[actual load kw/preset load kw]*100[%]
*Line type/DSP-VIP-PL ,round type/DSP-
VIP-PM
*indicating only ALhc(higher level alarm)
Alarm before
trip
*preset "AL" in "Au-o" mode ,then make
level % in "Alhc" mode
*1c is closed(energized) if actual level %
exceeds preset level %/Available even
when a condition is keeping for 3 sec
9.Auxiliary Function
Item
Description
Remarks
SC/F-MC/R
transfer timer
*Providing transfer time from Y to Delta
*Adjustable transfer time:1sec ~ 5 min
*Transit interval time from Y-End to D-Start :0.2
sec
*dt is available for each during Y and D contactor is
"on" state
DC 4~20mA
*To change max current among 3 phase into 20mA
*The receiver for 4-20 signal does not need loop
voltage
Password
*The preset procedure in a mode is possible as
inputing password for a exclusive operator to have
gurantee for operation
