*Main trip relay will be trip(energized) after count
down a preset o-time(dt or time of 550% in inverse)
in "Test" SW of converter or in press "CLR" SW
for 3 sec to check if a self-function is normal or
Auto Close
*In case a line power is "on" again within a preset
time after a line power is "OFF" during a normal
operation,main contactor is closed automatically
after another preset time(DOMT)
*Shut Down Delay Time:1~5sec
/Adjustable
*Delay On Make Time:0(instant)~25sec/
Adjustable by 5sec unit
*Expression in mode:eg/2-3:in case power is
"on" within 2sec after power-off,motor starts
after 15sec((3 is matched with 15sec)
from the instant of power-on
10. Self-diagnostics table
When the control power is on,the disply is shown in
the order as follows: LOP(default)
tE-no(if PT-
100 is not connected)
version NO.--> ON/OFF
control command position(one of LOP, MCC/display
LED on the communication module is not turned on
or not flickered
Fault for internal current board
Fault for internal voltage board
Fault for GR protection function in
internal main board
te-no;not possible to rum if a value is preset in"tep"
mode
Latest measured temperature
greater than preset temperature
"tep" and "latest measured value" is appeared
alternatively/not possible to run if preset value is not
changed
Test:by Test SW in converter or
"CLR" SW
Main trip(97-98) is tripped after counting down
preset o-time in definite T-I(550% time in inverse T-
I)/the number of lighted LED is matched with
counted time
