Samwha DSP DSP-VIP-PL - Logic Input Operations for PC & Meter; Logic Input Operations for FWD;REV & EFI

PC Duty
Logic
Input
High Low State
Output relay operation by Logic input
[C1-SC/F(P type),C-F(Rtype):Frdt=OFF]
4 O -
Motor
start/stop
in PC
C1-SC/F,C1-F→Close(start)
C1-SC/F,C1-F→Open(stop)
5 O -
Display Meter Duty(MCC)
Logic
Input
High Low State
Output relay operation by Logic input
[C1-SC/F(P type),C-F(Rtype):Frdt=OFF]
5 O -
Start/Stop
in Display
Meter
C1-SC/F,C1-F→Close(start
C1-SC/F,C1-F→Open(stop)
LOP-FWD/REV (PM,CM / RM,RTM)
Logic
Input
High Low State
Output relay operation by Logic input
[C1-SC/F(P type),C-F(Rtype):Frdt=OFF]
1 Low→High
Forward
Start
C1-SC/F,C1 - F→close
2 O -
2 - O
Forward
Stop
C1-SC/F,C1 - F→open
3 Low→High
Reverse
Start
C1-MC/R,C1 - R→close
2 O -
2 - O
Reverse
Stop
C1-MC/R,C1 - R→open
rcs-FWD/REV (PM,CM / RM,RTM)
Logic
Input
High Low State
Output relay operation by Logic input
[C1-SC/F(P type),C-F(R type):Frdt=OFF]
1 Low→High
Forward
Start
C1-SC/F,C1 - F→close
4 O -
1 - O
Forward
Stop
C1-SC/F,C1 - F→open
3 Low→High
Reverse
Start
C1-MC/R,C1 - R→close
4 O -
3 - O
Reverse
Stop
C1-MC/R,C1 - R→open
EFI(External Fault Input) Duty(Available for VIP-PM,CM /RM,RTM,5E)
Logic
Input
High Low State
Output relay operation by Logic input
[C1-SC/F(P type),C-F(Rtype):Frdt=OFF]
C1-M(5 series]
