Samwha DSP DSP-VIP-PL - Display Meter Components; Communication Module Components

○ Display Meter
○ Communication Module
RJ45 Connector Hole
With Cover/Input
10P Terminal
/5P-In,5P-
Out
Screw
Hole
9PIN D-Sub/
RS-232
<>Converter
DIP SW/4P:Termination
Resistence,485-422
Outside View
Inside View
Status
LED
9 PIN D-Sub/
RS232< > Converter
by Cable Connector
Menu Bar
5 Digit Display
OFF
Phase LED
ON
Control Key:w/Back
Light
UP
CLR
SET
Mode
DN
Front View
Key Cover
Lock Cover
Back View
Round Bar Grapgh
