3.Main Feature
Incoming voltage is indicated orderly while a motor is stopped
To give a guarantee to exclusive operator:Password Input
To realize convenient and various data input
• Display Meter: DSP-VIP-PM
• Note Book PC: DSP-VIP-PL,VIP-PM
Main/Sub/Cab Menu:Three devided menu group according to usage and the frequency of data input
• Main menu:Data input frequency is rather higher
• Sub menu:Ratherly common application for all kind of motor
• Cab (calibration) menu :adjustable for indicating value within narrow range
(
12.7%) /This menu is appeared when "SET" key is pressed for 5 sec or more
and disappeared right after pressing again.
Beautiful inside lighting by every touch button:Easy handling in dark space of the panel.
To Indicate a necessasary information in every 3 sec
• Basic Factor circulating indication:V,I,KW,GR(Ec)/ “OFF” must be set in ”rota” mode
• Basic Factor + PF,Temp,KWH,AWT(Accumulated Working Time)/“ON” must be
set in ”rota” mode/ Possible to fix one of circulated factor or to release:one touch
for CLR Key
• To show load factor(actual/setting)/65% ~ 100%:Line Type/DSP-VIP-PL
,Round Type/DSP-VIP-PM
To check preset value during motor run:done by adjusting "SET" & "Mode" key
*Press "SET" key during a motor run,then search mode neccessary to check
, consequently name of mode & preset value is shown alternatively
*not possible to change preset value,only to show preset state.
Duplex Alarm:Higher Alarm,Lower Alarm to OC/Lower Alarm is only possible in case “LinE”
mode is preset for “OFF”
ON-OFF switch/DSP-VIP-PM:to save wiring and labor inside panel
Convenient installation:65Phi circle or rectagular hole(48*96)/DSP-VIP-PM:Display Meter.
To indicate trip number of main contactor:contributing to check a replacing term and
effective maintenance.
To keep a stable operation under frequency variation of Inverter:1Hz ~ 400Hz
To call initialized factory setting value:press test button before power-on,then keep
pressing state for 3 sec after power-on.
Indication for a position of “ON”-"OFF' command to run a motor:in case motor is run or
stopped during the ation by "OFF" or "Auto sensor",a position message like LOP,MCC(Display
meter),rcs(Remote control sensor),out-F(external fault input) and PC that such command
was originated to is appeared in front message window.
Power type protection relay based on Voltage and Current
To indicate RMS value/Voltage,current:RMS chip adopted in every input/to contribute
to check an exact condition of motor
