(*note 1) : All time indicate (ST570, 540 is Option)
(*note 2) : Option (ST540 is SKIP)
※ Cool type will not workable at H/C Type.
※ OUT1, OH, OL is SKIP in ON/OFF Mode.(OUT1 is RLY control output)
The parameter to set Preset Output value for emergency output.
It makes output value in ‘Po’ after stopping control output calculated
by PID algorithm when stop or A/D Error, Sensor open.
The parameter to set Preset Output value for emergency cooling output in
H/C type. It makes a output set by Poc, it stops to make output by PID
calculation when stopping ,A/D ERROR or Sensor Open in AUTO Mode.
The parameter to set operation of MV OUT LAMP.
SSR : MV LAMP is blinking within CT when SSR or Relay control output.
SCR : MV LAMP is blingking irrespective of CT when SCR control output.
Sym Parameter
Setting Range
Unit Initial Remark
SUB2
O.ACT
CT
OH
OL
PO
Select Output
HEAT, COOL, ALM1, ALM2, ALM3, RUN
ABS ALM3 (*note 2)
Reverse and
Forward
REV, FWD
ABS REV
All time
indicate
Cycle Time 1
1 ∼ 300 sec
sec 2 sec
All time
indicate
High-Limit value
of Output
OL-L+1Digit ∼ 105.0%
HC Type : 0 ~ 105.0%, However OH>OL
% 100.0%
All time
indicate
Low-Limit value
of Output
-5.0% ~ OL-H-1 digit
HC Type : 0 ~ 105.0%, However OH>OL
%
0%
H/C:100.0%
All time
indicate
Preset Out1
-5.0 ∼ 105.0%
H/C Type : 0.0 ~105.0%
% 0.0%
All time
indicate
OUT1
OUT2
OUT3
HEAT
SUB1
Select Output
HEAT, COOL, ALM1, ALM2, ALM3, RUN
ABS ALM1
All time
indicate
Select Output
HEAT, COOL, RET
ABS HEAT
All time
indicate
Select Output
HEAT, COOL, RET
ABS RET (*note 1)
Select Ouput
Type
SSR, SCR
ABS SSR
When OUT 2,
3 is in ‘HEAT’
Select Output
HEAT, COOL, ALM1, ALM2, ALM3, RUN
ABS ALM2 Option
COOL
Select Ouput
Type
SSR, SCR
ABS SSR
When OUT 2,
3 is in ‘Cool’
CTc Cycle Time 2
1 ∼ 300 sec
sec 2 sec H/C TYPE
POc Preset Out2
0.0∼105.0%
% 0.0% H/C TYPE
0.0 ∼ 10.0%
% 0.5% H/C TYPE
HYS.H
HYSTERESIS
HIGH
EUS(0.0∼10.0%)
EUS EUS(0.5%)
ON/OFF
MODE
HYS.L
HYSTERESIS
LOW
EUS(0.0∼10.0%)
EUS EUS(0.5%
ON/OFF
MODE
HYS HYSTERESIS
O.LED OUTPUT LED
SCR, SSR
ABS SSR
All time
indicate
To Next Page
