The parameter to display control output status (OUT1, 2, 3, SUB 1, 2) of the
controller to the operation display.
You can check the control output status in operation display if ‘oStS’ sets.
The parameter to set High-Limited value display of Sensor Input in PV display
window. PV display window only shows the value of DSP.H even if it sets value
higher than DSP.H from the sensor. But controller operates in actual value
The parameter to set Low-Limited value display of Sensor Input in PV display
window. PV display window only shows the value of DSP.L even if it sets value
higher than DSP.L from the sensor. But controller operates in actual value
The parameter to set PASSWORD in Controller. Set U/PWD in PASSWORD
screen before entering control group (G.CTL) of parameter group.
Not allow for entering parameter group if input value is not the same as
registered password. Its initial setting U.PWD is ‘0’.
The parameter to initialize the controller. It is initialing when ‘INIT’ sets ‘ON’
(However, not allow communication for initializing)
- Be sure not to forget PASSWORD after registration.
- If Forget the PASSWORD, Not available for operator’s maintenance.
Need to return the controller for our service center and sales office.
It will be initialized all parameters of the controller when ‘INIT’ parameter sets.
Be sure to avoid any kind of inconvenience.
The parameter to set operation status of the controller in effect of external
contact input when it sets option(/DI). The Controller operation of DI.SL
setting is refer to ‘Table of DI Operation’ as shown on belows.
The parameter to set ON/OFF Mode. Control Output is OUT1(RLY) When set
ON/OFF Mode.
