S&C 6800 Series User Manual

Communication Status
The communication status bar at the bottom of the IntelliLink software screen displays
the connection addresses, the refresh mode, and the last refresh. The time changing
after “Refresh:” indicates the control is communicating. The refresh defaults to the
Auto setting, but it can be stopped by clicking on the Stop button and manually
refreshed by clicking on the Once button that comes into context when the refresh
is stopped.
IntelliLink
®
Setup Software
S&C Instruction Sheet 1045-530 19
