S&C 6800 Series User Manual

Switch Control Setup
Retry Timer
Enter the amount of time in seconds to wait before a retry is attempted. (Range: 0-255;
Step: 1; Default: 5)
Control Point Number
Enter the DNP control point number that activates the Prohibit Restoration mode in
the remote device. (Range: 0-255; Step: 1; Default: 0)
Commission Test
Selecting the Execute option from the drop-down menu sends a Prohibit Restoration
command to the target device(s) to perform the operation in the exact same manner that
will occur when the command is sent during normal operation.
WARNING
Performing a Commission Test will apply the Prohibit Restoration state to the
target device. The Prohibit Restoration state must be removed to put the device
in the Ready state.
Test Result
This indicates “Pass,” “Pending,” “Bad Response,” or “No Result” for the sent Prohibit
Restoration command. “Pass” means that the local device received an acknowledgement
from the remote device before the Retry Timer expired. “Pending” means that the local
device sent out the test command but is still awaiting a response. “Bad Response” means
that either the remote device rejected the command or the Retry Timer expired before
the local device received an acknowledgement. “No Result” means that no tests have
been performed yet.
Note: If DNP association of the peer device cannot be completed due to an incorrect
RTU address, IP address, or Port Code, the Test Result field may show a Pending status
indefinitely until the test is rerun again and the association can be made.
Enable Remote Transmit from Local P.R.
Enabling this option sends a Prohibit Restoration command to all devices in the list
when the Prohibit Restoration state is activated locally via the front panel or IntelliLink
screen.
Enable Remote Transmit from SCADA P.R.
Enabling this option will send a Prohibit Restoration command to all devices in the list
if any the following events are active when the Hot Line Tag mode or the Frequency
Trip state, Manual Operation state, or Prohibit Restoration state is activated from
a SCADA command from a congured master station address.
Remotely Clear Prohibit Restoration
Clicking on this button sends a Clear Prohibit Restoration command to the local device
and all devices in the list and will clear the local Prohibit Restoration state. If an event
is still active (Hot Line Tag mode, Frequency Trip state, Manual Operation state),
the Clear Prohibit Restoration command will not be sent.
Remote Transfer Trip List Section
Transfer Trip commands are sent from the device to distributed generation resources
within the distribution system immediately upon detection of a circuit anomaly so the
distributed generation does not interfere with IntelliTeam system restoration activities.
This action is both for safety reasons and for the protection of load.
If the local device trips open due to a Protection or Automatic Sectionalizing event,
and the Transfer Trip feature is enabled, Then, it sends Transfer Trip commands to
all devices, whether S&C controls or 3rd party controls, listed on its Remote Transfer
Trip List. The Transfer Trip messages are sent, no matter what state the distributed
generation/distributed energy resources is in at the time, to ensure it is disconnected
from the system. When the trip is due to a Protection event the Transfer Trip messages
will initiate following the initial trip. Lockout state is not necessary.
62 S&C Instruction Sheet 1045-530
