S&C PMH-3 User Manual

S&C Instruction Sheet 662-510 29
Appendix C
Table 4. Optional Features—Continued
Item
Suffix to be Added to
Pad-Mounted Gear
Catalog Number
Applicable to Models
Base spacer, compartmented to match
enclosure, increases cable-termination
height
Carbon steel
6 inches (152 mm) -K1 All models
12 inches (305 mm) -K2 All models
18 inches (457 mm) -K3 All models
24 inches (610 mm) -K4 All models
Stainless steel
6 inches (152 mm) -K11 All models
12 inches (305 mm) -K12 All models
18 inches (457 mm) -K13 All models
24 inches (610 mm) -K14 All models
Base spacer, noncompartmented,
increases cable-termination height
Carbon steel
6 inches (152 mm) -K7 All models
12 inches (305 mm) -K8 All models
18 inches (457 mm) -K9 All models
24 inches (610 mm) -K10 All models
Stainless steel
6 inches (152 mm) -K17 All models
12 inches (305 mm) -K18 All models
18 inches (457 mm) -K19 All models
24 inches (610 mm) -K20 All models
International crating
① -L71 All models
Switch- and bus-terminal adapters—for connection of two cables (through 750 kc mil)
per terminal
②
Note: Space limitations prevent use of these adapters where surge arresters are to be installed
-M1 All models
Cable guides, one at each terminal
②③
In switch and bus compartments.
For conductor sizes No. 2 through
1000 kc mil
-M2 All models
In fuse compartments. For
conductor sizes No. 2 through 4/0
-M3
PMH-4, -5, -6, -11,
-19
PMH-7, -8, -9
PMH-12
Polymer-housed metal-oxide surge arresters
④,
base-mounted, at switch terminals and bus terminals
in compartments 1 and 2 (removed for shipment)
9 kV
-N6
●
All models
10 kV
-N7
●
All models
12 kV -N8 All models
15 kV -N9 All models
18 kV
-N10
■
All models except
PMH-19
Metal-oxide surge arresters
④, base-mounted, at switch
terminals and bus terminals in Compartments 1 and 2
(removed for shipment)
3 kV
-N11
▲
All models
6 kV
-N12
▲
All models
① Wood products used in the packaging are either hardwood or certified
by the wood supplier as being “heat treated (kiln dried) to a core
temperature of 133°F (56° Celsius) for a minimum of 30 minutes.”
② When catalog number suffix “-M1” or “-M2” is specified, cable-
termination options (catalog number suffixes “-U2” and “-U3”) cannot
be accommodated. In addition, when catalog number suffixes “-M1”
and “-M2” are both specified, only one cable guide is pro vided at each
switch terminal.
③ These devices extend below the base of the unit. Provide a cable pit
or specify a base spacer that provides a 12-inch (305 mm) or greater
increase in cable-termination height.
④ Surge arresters are base-mounted only (without isolators).
● Not applicable to 25-kV models.
■ Not applicable to 14.4-kV models.
▲ A supplemental label is provided for catalog number suffixes “-N11”
and “-N12” indicating the voltage rating of the surge arresters furnished.
