S&C Instruction Sheet 662-510 5
Safety Information
A
A
B
F
F
C
E
C
D
D
Hazardous voltage—more than 4000 volts.
Failure to follow these instructions will likely
cause shock, burns, or death.
• ALWAYS consider all circuits and component
parts live until completely de-energized, tested,
grounded, and tagged or properly identified.
• Do not work on or near this equipment
unless you:
(1) Know and obey your employer’s work
rules and S&C’s instruction sheets
d
(in
Compartment 1); and
(2) Know the hazards involved with this
high-voltage equipment.
• ALWAYS use proper personal protective
equipment, protective devices, and tools
suitable for the assigned task.
d Note: Additional instruction sheets are available free of charge
from S&C by calling (773) 338-1000.
DANGER
G-6503R1
DANGER
KEEP AWAY
Hazardous voltage—more
than 4000 volts.
Will shock, burn, or cause
death.
•Qualiedpersonsonly.
•Ifopen,immediatelycall
electriccompany.
G-6500
Do not leave barrier in this position
for more than one week.
Barrier damage could result
which can cause flashover and
injury.
G-6399
DRAWING NO.
G-9137
DESCRIPTION DRAWING NO.
DUAL PURPOSE BARRIER LABEL AND CABLE TIE REMOVAL LABEL
15 & 25KV PMH
G-9137
PROPRIETARY STATEMENT: THIS DOCUMENT AND ALL PREVIOUS ISSUES ARE THE SECRET AND CONFIDENTIAL PROPERTY OF S&C ELECTRIC COMPANY (“S&C”), 6601 NORTH RIDGE BOULEVARD, CHICAGO, ILLINOIS,
AND NEITHER RECEIPT NOR POSSESSION THEREOF INFERS OR TRANSFERS ANY RIGHT IN OR LICENSE TO USE THIS DOCUMENT, THE SUBJECT MATTER THEREOF, OR ANY DESIGN OR TECHNICAL INFORMATION
SHOWN THEREON, OR ANY RIGHT TO REPRODUCE THIS DOCUMENT OR ANY PART THEREOF. NEITHER THIS DOCUMENT NOR ANY INFORMATION CONTAINEDTHEREIN MAY BE COPIED, REPRODUCED, OR OTHERWISE
USED OR DISCLOSED TO ANY OTHER PARTY WITHOUT FIRST OBTAINING THE EXPRESS WRITTEN PERMISSION OF S&C. THIS DOCUMENT IS PROVIDED UNDER THE EXPRESS CONDITION THAT IT WILL BE HELD IN
CONFIDENCE BY THE RECIPIENT, THAT IT IS SUBJECT TO RETURN UPON DEMAND, AND THAT IT WILL NOT BE USED IN ANY WAY DETRIMENTAL TO S&C.
SCALE MATERIAL:
S&C SPEC. NO.
DESCRIPTION
.004 WHITE VINYL W/ .001 MYLAR LAMINATION ACRYLIC
BASE ADHESIVE. S&C SPEC, MSP-0083
REVISIONS
FULL
NO. DATE NOTICE NO.
DRAWN BY FINISH:
S&C SPEC. NO.
DESCRIPTION
O THER. SEE BELOW
000 1-17-05 84823
MN
CH. BY
TYP. PMX MES
EFH. OPTION
PMH
UNLESS OTHERWISE SPECIFIED:
DECIMAL DIMS TO BE
!
.031
APP. BY
NEXT
ASSEMBLY
PRODUCT
DESCRIPTION
FRACTIONAL DIMS TO BE
!
AK
ANGLES TO BE !
DAT E
USED ON
WHEN CHECKED, BREAK ALL CORNERS g
1-17-05
WHEN CHECKED, REMOVE ALL BURRS g
s
S&C ELECTRIC COMPANY
G E N E R A L O F F I C E S • C H I C A G O
5.0
G-9137
.125
R. TYP
3.375
Specialists in Electric Power Switching and Protection
NOTICE
1.0
HANG THIS DUAL PURPOSE BARRIER
ON THE SWITCH BARRIER MOUNTING
ANGLE AND REMOVE THE CABLE TIES
FROM THE INTERPHASE BARRIERS
BEFORE ENGERGIZING THE SWITCH-
GEAR.
WHITE CHARACTERS ON
BLACK BACKGROUND
BLACK CHARACTERS ON
WHITE BACKGROUND
Location of Safety Labels
To Next Page
