TECHNICAL SPECS AND OPERATING LIMITS
82005-PG-D SANDEL SN3500 EHSI PILOT’S GUIDE PAGE 11-1
CHAPTER 11 TECHNICAL SPECS AND OPERATING LIMITS
TSO Compliance
Technical
Standard Order
(TSO):
TSO-C113, Airborne Multipurpose electronic Displays
Software
Certification:
RTCA/DO-178B, Level C
Environmental
Category:
DO-160D
High Vibration:
[(A2)(F1)]ZBAB[(H)(R)]XXXXXXZBABB[WW]M[XX(E2)(F2)X]
XXA
Standard:
[(A2)(F1)]ZBABHXXXXXXZBABB[WW]M[XX(E2)(F2
)X]XXA
Physical Dimensions
Form Factor: 3ATI (ARINC 408)
Width: 3.165 in. (8.04 cm)
Height: 3.165 in. (8.04 cm)
Length: 10.3 in. (26.2 cm) overall, excluding
connectors and knobs.
Weight: 3.0 lbs (1.4 Kg)
Operational Characteristics
Temperature/Altitude: -20º C to + 70º C up to 55,000 ft.
Power Inputs: 22 to 33 VDC
1.5 Amperes nominal @ 27.5 VDC
400 HZ Reference: 26 volts nominal, less than 1 milliampere
load
