Model HDB3/HDB4 • 17
Service and Repair Kits Composite Repair Parts List
1* 031.021.010 Assembly, Main Air Valve 1
2 050.014.360 W Ball, Check 4
050.014.364 W Ball, Check 4
050.014.365 W Ball, Check 4
050.015.600 Ball, Check 4
3 060.012.000 Base, Pump (Top Ported) 1
060.013.000 Base, Pump (Bottom Ported) 1
4 070.017.170 Bearing, Sleeve 2
5 095.073.001 Assembly, Pilot Valve 1
6 114.003.010 Bracket, Intermediate 1
7 132.012.360 Bumper 2
8 135.016.162 Bushing, Threaded 2
9 170.015.330 Capscrew,
Hex Hd, 5/8-11 X 2.75 4
10 170.034.330 Capscrew,
Hex Head 1/2-13 Unc X 2.00 14
11 170.045.330 Capscrew,
Hex Head 5/16-18 X 1 1/4 4
12 170.064.330 Capscrew,
Hex Hd, 5/8-11 Unc X 2.25 2
13 170.065.110 Capscrew,
Hex Hd, 3/4-10 X 2.25 2
14 170.066.330 Capscrew,
Hex, 1/2-13 X 2.25 24
15 196.031.010 Chamber, Outer 2
196.031.110 Chamber, Outer 2
16 196.032.010 Chamber, Inner 2
17 286.047.604 Diapragm, Overlay 2
18 286.048.354 Diaphragm, Backup 2
(Use With PTFE Overlay
and Santoprene)
286.014.360 Diaphragm 2
286.014.363 Diaphragm 2
286.014.364 Diaphragm 2
286.014.365 Diaphragm 2
19 312.031.010 Elbow, Manifold 2
312.031.110 Elbow, Manifold 2
20 334.023.010 Flange, Porting 2
334.023.110 Flange, Porting 2
21 360.041.379 Gasket, Pilot Valve 1
22 360.046.425 Gasket, Manifold 2
360.046.603 Gasket, Manifold 2
23 360.048.425 Gasket, Air Valve 1
24 510.002.020 Lug, Clamp 4
25 518.023.010 Manifold 1
518.023.110 Manifold 1
26 530.038.000 Muer 1
27 544.003.330 Nut, Hex, 5/8-11 Unc 4
28 545.008.330 Nut, Hex, 1/2-13 24
29 545.009.330 Nut, Hex, 5/8-11 Unc 10
30 560.001.360 O-Ring 2
31 560.045.360 O-Ring 2
32 560.207.360 O-Ring 8
560.207.363 O-Ring 8
560.207.364 O-Ring 8
560.207.365 O-Ring 8
32 720.074.608 Seal, Ring 8
33 570.010.360 Pad, Wear 2
570.010.363 Pad, Wear 2
570.010.364 Pad, Wear 2
570.010.365 Pad, Wear 2
34 612.063.110 Plate, Outer Diaphragm 2
612.063.330 Plate, Outer Diaphragm 2
35 612.085.330 Plate, Inner Diaphragm 2
612.113.156 Plate, Inner Diaphragm 2
(Use With PTFE Overlay Only)
36 618.003.110 Plug, Pipe, 1/4 2
618.003.330 Plug, Pipe, 1/4 2
37 620.011.114 Plunger, Actuator 2
38 675.021.360 Ring. Sealing 2
675.021.363 Ring. Sealing 2
675.021.364 Ring. Sealing 2
675.021.365 Ring. Sealing 2
675.021.366 Ring. Sealing 2
38 675.021.600 Ring. Sealing 2
39 685.030.120 Rod, Diaphragm 1
40 720.014.360 Seal 2
41 722.128.010 Check Valve Seat 4
722.128.110 Check Valve Seat 4
42 807.085.330 Stud, 5/8-11 X 3.75 14
43 900.003.330 Washer, Lock, 1/2 14
44 900.007.330 Washer, Lock, 5/8 16
HDB4 Model Components
(In Addition To The Parts Above)
45 334.037.010 Flange, Adapter 2
46 360.036.426 Gasket, Flange 2
29 545.009.330 Nut, Hex, 5/8-11 Unc 8
47 807.005.330 Stud, 5/8-11 X 2.50 8
44 900.007.330 Washer, Lock, 5/8 8
360.083.360 Gasket, Spacer
(used with Santoprene Diaphragms) 2
ATEX Compliant
LEGEND:
= Items contained within Air End Kits
= Items contianed within Wet End Kits
* Air End Kit includes sleeve and spool set, not entire air valve
assembly
Note: Kits contain components specic to the material codes.
MODEL SPECIFIC
3: EXP VIEW
