Model HDB3/HDB4 • 5
Explanation of Pump Nomenclature
ATEX Detail
Diaphragm Check Valve Materials
B Nitrile
C FKM with PTFE
GN Neoprene Backup with PTFE Overlay
and PTFE Check Balls
H EPDM with PTFE
I EPDM
N Neoprene
S Santoprene
U Santoprene with PTFE
Design Level
4
Construction
SI Stainless Steel Wetted, Cast Iron Air
CI Cast Iron Wetted, Cast Iron Air
Pump Series
HD Heavy Duty
Pump Design
B Soilid Ball
Pump Size
3 3"
4 4"
Discharge Porting Position
D Bottom
T Top
Options
P1 Intrinsically Safe ATEX Compliant
Pulse Output
Your Serial #: (ll in from pump nameplate) _____________________________________
__ __ _____ __ ___ __ __
Pump Pump Pump Size Discharge Diaphragm/ Design
Construction
Series Design and Options Porting Valve Level
XX X XXXXXX, XX XXX X XX
Model #:
(ll in from pump
nameplate)
Your Model #:
ATEX Details
Wetted
Material
Options
Non-Wetted
Material
Options
Pump
Options

Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
H, S C 6 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
A, H, S A, C, Y **0, 6 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
A, H, S A, C, Y **0, 6 P1
II 2 G Ex h mb IIC T5 Gb
II 2 D Ex h mb tb IIIC T100°C Db
A, H, S A, C, Y **0, 6 A1, A2, A3, A4
S05 M
ATEX Details
Wetted
Material
Options
Non-Wetted
Material
Options
Pump
Options

Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
H, I, S I, Z 6 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
A, H, I, S, X A, I, Y, Z 6 00
II 2 G E x h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
A, H, I, S, X A, I, Y, Z 6 P1
II 2 G Ex h mb IIC T5 Gb
II 2 D Ex h mb tb IIIC T100°C Db
A, H, I, S, X A, I, Y, Z 6 A1, A2, A3, A4
S1F M, M1F Remove wetted material option X
**Pump option 0 is only ATEX compliant with non-wetted material option C
ATEX Details
Wetted
Material
Options
Non-Wetted
Material
Options
Pump
Options

Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
H, I, S I, S, Z 6 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
A, H, I, S, X A, I, S, Y, Z 6 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
A, H, I, S, X A, I, S, Y, Z 6 P1
II 2 G Ex h mb IIC T5 Gb
II 2 D Ex h mb tb IIIC T100°C Db
A, H, I, S, X A, I, S, Y, Z 6 A1, A2, A3, A4
S15,S20,S30 M
ATEX Details
Wetted
Material
Options
Non-Wetted
Material
Options
Pump
Options

Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
C, V C 6 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
C, V C 0, 6 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
C, V C 0, 6 P1
II 2 G Ex h mb IIC T5 Gb
II 2 D Ex h mb tb IIIC T100°C Db
C, V C 0, 6 A1, A2, A3, A4
S05, S1F NM
ATEX Details
Wetted
Material
Options
Non-Wetted
Material
Options
Pump
Options

Options
I 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
C C 6 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
C C 0, 6 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
C C 0 ,6 P1
II 2 G Ex h mb IIC T5 Gb
II 2 D Ex h mb tb IIIC T100°C Db
C C 0 ,6 A1, A2, A3, A4
S15,S20 NM
ATEX Details Construction Options
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
CA 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
CA P1
PB1/4
ATEX Details
Wetted
Material
Options
Non-Wetted
Material
Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
S S, T, 7, 8, 9
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
All Options All Options
G15, G20, G30
ATEX Details Construction Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
II, SI, HI N/A
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
A, CI, II, HI, HC, SI, SS P1
ST1 1/2
ATEX Details Construction Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
II, SI 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
A, I, SI, SS 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
A, I, II, SI, SS P1
ATEX Details Construction Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
SI, HI 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
A, SI, SS, HC, HI 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
A, HC, HI, SI, SS P1
HDF1, HDF2
SB1, SA1
ATEX Details Construction Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
II 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
II P1
HDF3M
ATEX Details Construction Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
CI, SI 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
CI, SI P1
HDB3
ATEX Details Construction Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
SI, HI, II 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
A, CI, SS, HC 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
A, CI, II, HI, HC, SI, SS P1
HDB2
ATEX Details Construction Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
SI, II 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
A, CI, SS 00
II 2 G Ex h ia IIC T5 Gb
II 2 D Ex h ia IIIC T100°C Db
A, CI, II, SI, SS P1
HDB1
ATEX Details Construction Options
II 1 G Ex h IIC T5...225°C (T2) Ga
II 1D Ex h IIIC T100°C...T200°C Da
I M1 Ex h I Ma
II, SI 00
II 2 G Ex h IIC T5...225°C (T2) Gb
II 2 D Ex h IIIC T100°C...T200°C Db
A, I, SI, SS 00
HDF3A
