INSTALLATION
Installing Your Dishwasher
Please refer to this guide for the installation process.
1. Remove all packaging before positioning the machine.
2. Please ensure the dishwasher is installed by a qualified technician.
3. Unscrew the two screws and adjust the distance of left and right plinth tab to your need. The
adjustable range is from 39mm to 134mm.
4. Fix the plinth on the plinth tab. According to your need to adjust the plinth height, the adjustable
range is from 56mm to 122mm.
screw
SCREW
CONE GEAR
screw
plinth
plinth tab
