Table 6 - Replacement Parts S17A & S23A
Item No. Description
S17A S23A
Quantity Part Number Quantity Part Number
1 Easy-Off End Cap 2 25-1499A1 2 25-1499A1
2 Rubber O-ring, Static Gland 2 00-1108B 2 00-1108B
3 Lamp Spacer 2 25-0210A 2 25-0210A
4 Lead Wire & Socket 2 05-1219B2 2 05-2223A
5 Lamp 1 05-1098-R 1 05-1097-R
6 Static Gland Nut 2 25-1492D 2 25-1492D
7Tefl on® Washer 2 25-1235A 2 25-1235A
8 Rubber O-ring, Quartz Sleeve 2 00-1238A 2 00-1238A
9 Quartz Sleeve 1 15-1051A2 1 15-1051A3
10 Head, Flared 1 25-1302A 1 25-1302A
11 Rubber O-ring, Flared Head 1 00-0028A 1 00-0028A
12 Chamber Head Clamp 1 25-1506B1 1 25-1506B1
13 Wiper Rod Assembly 1 25-0083A 1 25-0084A
14 Sight Port Plug 1 30-1075 1 30-1075
15 Chamber 1 25-1524D1 1 25-1523E1
16 Wiper Knob 1 25-1222 1 25-1222
17 Wiper Lock Spacer 1 25-1512A1 1 25-1512A1
18 Wiper Clip 1 25-1507C1 1 25-1507C1
19 Dynamic Gland, Wiper Lock 1 25-1510C1 1 25-1510C1
20 Drain Plug 1 27-1216 1 27-1216
21 Screw, No. 8 x 3/8” long 4 50-1323 4 50-1323
22 Speed Nut, 6-32 2 50-1314 2 50-1314
23A Ballast, 120v 60Hz 1 10-0137 1 10-0137
23B Ballast, 220v 50Hz 1 10-0136 1 10-0136
24 Screw, Mounting 2 50-0376 2 50-0376
25 Ballast Housing 1 25-1105C 1 25-1544E
26 Pushnut 8 50-1223A 8 50-1223A
27 Welded Wiper Rod 1 25-1535A1 1 25-1536A1
28 Tefl on® Wiper Segment 4 25-1241A 4 25-1241A
29 Wiper Backup Ring 2 25-1381A 2 25-1381A
30 Rivet 8 50-1300A 8 50-1300A
31A* Power Cord 6’ (120v 60Hz) 1 35-1100 1 35-1100
31B* Power Cord 6’ (220v 50Hz) 1 35-1452-R 1 35-1452-R
32 Standoff, Mounting 2 50-0375 2 50-0375
* not depicted in drawing
All specifi cations, dimensional data, etc are approximate and subject to change without notice.
