3.11.7 TEST MODE
The system can be put into test mode to check correct operation. For use by installation engineers
normally.
Test mode parameter (Preset modes, do not modify)
TEST MODE CONFIG
Start test mode parameters
STAGE 0
Mode 0
SWITCH_SECOND 4
Pressing the power key for 4 Seconds enters test mode 0
RELAY_HOLD_SECOND
-5570590
5570590 = 0x0055001e
55-> 85 gal, 1e-> 30 seconds
PLAY_FILE 2.wav
Play audio files2.wav
RELAY2 ON
Drive RELAY2
STAGE 1
Mode 1
SWITCH_SECOND 6
Pressing the power key for 6 Seconds enters test mode 1
RELAY_HOLD_SECOND 6
Drive RELAY for 6 seconds
PLAY_FILE 3.wav
Play audio files3.wav
RELAY1 ON
Drive RELAY1
STAGE 2
Mode 2
SWITCH_SECOND 8
Pressing the power key for 8 Seconds enters test mode 2
RELAY_HOLD_SECOND 8
Drive RELAY for 8 second
PLAY_FILE 4.wav
Play audio files4.wav
