Santos PS - MACHINE TECHNICAL SPECIFICATIONS

SANTOS : User and maintenance manual
MACHINE TECHNICAL SPECIFICATIONS
ELECTRICAL SPECIFICATIONS (1)
Model
# 1, # 1PS # 4
Supply voltage .(V) 220-240 100-120 220-240
Fre
q
uenc
y
(
Hz
)
50 50/60 60
Motor:
Power input (W) 600 650 650
S
p
eed
(
r
p
m
)
1500 1500/1800 1800
Average capacity (kg/h) 14 14
Hopper capacity (kg) 1 1
Grind drawer capacity (kg) 0.800
Maximum bag height (mm) 150 280
Dimensions: Height (mm) 550 700
Width (mm) 250 220
Depth (mm) 320 320
Weight: Net weight (kg) 15 19
Packaged weight (kg) 16 20,4
Noise : (2) L
pA
incertitude K
pA
= 2.5dB
(dBA) 74 74
(1) These ratings are provided as a rough guide. The exact electrical specifications can be found
on the rating plate.
(2) Noise level measured with sound pressure appliance in operation 1 m from its centerline in
accordance with standard EN 31201.
98101 US 3.0 - 09 2007 10 / 20 www.santos.fr
