SANTOS : User and maintenance manual
ITEM Description
1 Bean hopper cover
2 Bean hopper
3 Bean hopper shutter
4 Adjusting dial
5 Adjuster button attachment
6 Grinding wheel gap adjuster button
7 Dial fastening screw
8 Bag grip cord
9 Bag grip strap
10 Grind outlet tube
11 Base
12 Non-slip feet
13 On-off switch
14 Thermal overload switch, with reset
15 Grinding unit
16 Grinding unit clamp nut
17 Grinding wheels
18 Mobile grind wheel carrier plate
19 Fixed grind wheel carrier plate
98101 US 3.0 - 09 2007 19 / 20 www.santos.fr
