Sanus BLL2 - Step 1.1: Select TV Screws; Step 1.2: Determine Spacer Need

7
TV Bracket
TV Bracket
a
b
CAUTION: Verify adequate thread engagement with your
screw/washer/spacer combination AND the TV brackets. (STEP 1.2).
TOO SHORT will not hold the TV and TOO LONG will damage the TV.
M6
M8
1.1 Select TV Screws
Determine which screw diameter (M6 or M8) fits the four
mounting holes on the back of your TV.
1.2 Determine Spacer Need
Too Short Correct Too Long
Round BackCables
Inset Holes
Flat Back
1311 12
131211
131211
If your TV included inset spacers or wall mount
adapters, see Troubleshooting on PAGE 28.
TV Bracket TV Bracket TV Bracket
11
1212
For flat-back TVs, no
spacers
11
,
12
or
13
are required.
For rounded-back TVs, cable interference or
inset holes, spacers
11
,
12
or
13
to create
extra space between the TV and TV bracket.
131211
