Install using the spacer, screw and washer combination you
selected for your TV.
1.3 Attach TV Bracket Assembly to TV
Center the TV brackets
01
over your TV's mounting hole pattern as
shown - making sure the brackets are at the same height.
1
POSITION
TIP:
The cords
C
on TV brackets
01
should be oriented on the
bottom on the TV.
C
C
C
To Next Page
