Sanus BMT1 - Page 10

10
4. Place the wall plate template
06
at your desired height and position the slotted holes over your stud center lines. Level the wall plate
template
06
and tape in place.
NOTE: For assistance in determining wall plate location, see HeightFinder at sanus.com.
IMPORTANT: Be sure you mark and drill into the center of the stud.
5. Drill the four pilot holes using a 7/32 in. (5.5 mm) diameter drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 3 in. (75 mm).
0606
4 5
3 in. (75 mm)
7/32 in.
(5.5 mm)
