Sanus BMT1 - Page 26

26
07
C
C
12
11. Install the four screws
S2
*
and washers
S3
*
(into the anchors
S1
*
) and firmly tighten until the washers are pulled flush against
the wall plate
07
.
CAUTION: Avoid potential personal injury or property damage! All four screws
S2
*
MUST BE firmly tightened to prevent
unwanted movement of the wall plate
07
. Ensure the wall plate is securely fastened to the wall before continuing on to the next step.
12. Slide the covers
C
closed on wall plate
07
.
11
S3S2
S3S2
07
07
DOUBLE STUD
SINGLE STUD
S1
S1
