Parts and Hardware for STEP 2
NOTE: Not all hardware included will be used.
WARNING: This product contains small items that could be a choking hazard if swallowed.
Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged
item to your dealer; contact Customer Service. Never use damaged parts!
M8 x 50mm
For concrete installations ONLY
2.5mm
22mm
M6 x 12mm
M6 x 20mm
M6 x 35mm
M8 x 40mm
M8 x 20mm
M8x30 mm
5mm
5/16 x 2¾ in.
5/16 in.
Wall Plate
Wall Plate
Template
Lag Bolt
09 x4
10 x4
06 x1
07 x1
Concrete Anchor UX10 x 60R
CAUTION: Do not use in drywall or wood
Washer
08 x4
To Next Page
